Nanobeam M5-16
ITCurry #: N3302145 | Article #: NBE-M5-16-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Incorporating innovative industrial design with advanced technology, the NanoBeam M is the latest generation of Ubiquiti Networks airMAX CPE for customer locations.
Plug and Play Installation
The NanoBeam mounts to a variety of surfaces including poles or walls, and offers the freedom of three-axis alignment. No screws are required for pole-mounting, and only a single wall screw (not included) is required for wall-mounting.
Incredible Antenna “Beam” Performance
The form factor of the NanoBeam features the highest gain for its size. The NanoBeam’s excellent beam directivity provides the best performance in high-noise environments.
Advanced Software Technology
Ubiquiti’s airMAX technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.
| Prestatie | |
| Frequentieband | 5 GHz |
| Antenne versterkingsniveau (max) | 16 dBi |
| Kenmerken | |
| Polarisatie | Dubbele polarisatie |
| Montage | Muur |
| Kleur van het product | Wit |
| Certificering | FCC, IC, CE |
| Energie | |
| Stroomvoorziening | 24V |
| Stroomverbruik | 500 mA |
| Technische details | |
| Certificaten van naleving | RoHS |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 95 procent |
| Gewicht en omvang | |
| Breedte | 140 mm |
| Diepte | 140 mm |
| Hoogte | 54 mm |
| Gewicht | 320 g |
| Inhoud van de verpakking | |
| Aantal per verpakking | 1 stuk(s) |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85177100 |
| Warranty | |
| Base Warranty | Non Non |
