Product Informatie
PoE Switches for Your Ultra Convenience
8-Port Gigabit Easy Smart Switch with 4-Port PoE
Surveillance
Work with IP Cameras
Conference Call
Work with IP Phones
Wi-Fi Coverage
Work with Omada EAPs
Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).
Intelligent Power Management
When total power consumption excels 55W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.
Management Made Easy
TL-SG108PE offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, the TL-SG108PE offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.
Sturdy Metal Casing
Sturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L2 |
| Quality of Service (QoS) | Ja |
| Web-gebaseerd management | Ja |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 8 |
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
| Aantal Gigabit Ethernet (koper)-poorten | 8 |
| Netwerk | |
| Netwerkstandaard | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| 10G support | Nee |
| Ondersteundende kabel types | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Port mirroring | Ja |
| Verbindingsaggregatie | Ja |
| Broadcast stormbeheer | Ja |
| Auto MDI/MDI-X | Ja |
| Auto-negotiation | Ja |
| VLAN=ondersteuning | Ja |
| Virtuele LAN-functies | Port-based VLAN |
| Aantal VLANs | 32 |
| Data-uitwisseling | |
| Switchingcapaciteit | 16 Gbit/s |
| Verzending snelheid | 11,9 Mpps |
| MAC-adrestabel | 4000 entries |
| Store-and-forward | Ja |
| Jumbo Frames ondersteuning | Ja |
| Jumbo frames | 15000 |
| Packet buffergeheugen | 1,5 MB |
| Beveiliging | |
| IGMP snooping | Ja |
| Bescherming lus | Ja |
| Design | |
| Kleur van het product | Zwart |
| LED-indicatoren | Activiteit, Link, Power over Ethernet (PoE), Stroom, Snelheid, Status |
| Certificering | FCC, CE, RoHS |
| Energie | |
| Stroombron | DC |
| Vermogenstoevoer inclusief | Ja |
| Stroom | 1.25 A |
| Ingangsspanning | 48 V |
| Vermogensverbruik (max) | 65,2 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Ja |
| Hoeveelheid Power over Ethernet (PoE) ports | 4 |
| Vermogen per poort Power over Ethernet (PoE) | 15,4 W |
| Totaal Power over Ethernet (PoE)-budget | 64 W |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Warmtedissipatie | 256,19 BTU/h |
| Gewicht en omvang | |
| Breedte | 158 mm |
| Diepte | 101 mm |
| Hoogte | 25 mm |
| Verpakking | |
| Meegeleverde kabels | AC |
| Gebruiksaanwijzing | Ja |
| Type verpakking | Doos |
| Breedte verpakking | 131 mm |
| Diepte verpakking | 196 mm |
| Hoogte verpakking | 121 mm |
| Gewicht verpakking | 890 g |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
