Unified Controller Uc3400 12-bay
ITCurry #: M6054763 | Article #: UC3400-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Reliability and High Availability
Active-active dual controllers work simultaneously to ensure zero downtime in the event of a controller failure while the non-transparent bridge (NTB) enables inter-domain communication to maximize the protection of in-flight data.
Active-Active SAN with enterprise-class performance
Designed for mission-critical environments, UC3400 is a high-availability SAN solution supporting Fibre Channel (FC) and iSCSI protocols. With over 180,000 4K random write IOPS, it supports a wide range of demanding workloads.
Virtualization-ready
Full certification for VMware, vSphere, Microsoft Hyper-V, Citrix XenServer, and OpenStack environments
Support for Windows Offloaded Data Transfer (ODX), VMware vSphere Storage APIs Array Integration (VAAI), and ALUA ensure optimized and efficient storage operations
OpenStack® Cinder support enables UC3400 to become a block-based storage component
Flexible network options
Boost network from 10GbE and dual 1GbE RJ-45 ports to 10/25 Gb Ethernet cards or 16 Gb Fibre channel host bus adapters on each controller.
Built-in data protection and security
Maximize service uptime for critical services and enhance data security with snapshot protection and self-encrypting drive support in UC3400.
Storage expansion
Simple capacity expansion of up to 576 TB of raw storage is available with two Synology RXD1219sas Expansion Units.
Performance backed by Synology drives
Leverage high sustained performance and reliability with enterprise-grade drives with built-in protection designed for Synology systems.
| Opslagmedia | |
| Capaciteit opslag-drive | 0 GB |
| Opslag schijf-interface | Serial Attached SCSI (SAS) |
| Opslagschijf afmetingen ondersteund | 2.5,3.5" |
| RAID support | Ja |
| Soorten RAID | 0, 1, 5, 10, JBOD |
| Hot-swap drive bays | Ja |
| Ondersteunde bestandsystemen | BTRFS, ext4 |
| Opslagdrives ge‹nstalleerd | Nee |
| Totale ge‹nstalleerde opslagcapaciteit | 0 TB |
| Aantal storage drives ondersteund | 12 |
| Ge‹nstalleerde opslag-drive | Nee |
| Ondersteunde types opslag-drives | HDD & SSD |
| Processor | |
| Processorfabrikant | Intel |
| Processorfamilie | Intel© Xeon© D |
| Processormodel | D-1541 |
| Frequentie van processor | 2,1 GHz |
| Maximale turbofrequentie van processor | 2,7 GHz |
| Aantal processorkernen | 8 |
| Processor cache | 12 MB |
| CPU configuratie (max) | 1 |
| Geheugen | |
| Intern geheugen | 8 GB |
| Intern geheugentype | DDR4 |
| Ondersteund maximum RAM | 64 GB |
| Netwerk | |
| Ethernet LAN | Ja |
| Ethernet LAN, data-overdrachtsnelheden | 10,100,1000,10000 Mbit/s |
| Ondersteunde netwerkprotocollen | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| Verbindingsaggregatie | Ja |
| Poorten & interfaces | |
| USB-poort | Nee |
| Aantal Ethernet LAN (RJ-45)-poorten | 3 |
| Design | |
| Type behuizing | Rack (2U) |
| Type koeling | Actief |
| Aantal ventilatoren | 2 ventilator(en) |
| Ventilator diameter | 6 cm |
| Prestatie | |
| Soort | NAS |
| Backup-functie | Ja |
| Snap shot | Ja |
| Access Control List (ACL) | Ja |
| Reset button | Ja |
| Energie | |
| Capaciteit voedingsunit (PSU) | 500 W |
| Aantal voedingen | 2 |
| Redundante voeding | Ja |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50/60 Hz |
| Gewicht en omvang | |
| Breedte | 482 mm |
| Diepte | 724 mm |
| Hoogte | 88 mm |
| Gewicht | 19,7 kg |
| Processor speciale functies | |
| Versie Intel© Secure Key Technology | 1,00 |
| Versie Intel© TSX-NI | 1,00 |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 35 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 95 procent |
| Temperatuur bij opslag | -20 - 60 øC |
| Warranty | |
| Base Warranty | Non Non |
