Flashstation Fs3600 24bay 2u All-flash Nas Server Bareborn
ITCurry #: M6054094 | Article #: FS3600-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Fast and scalable all-flash NAS
FS3600 is a 24-bay all-flash Synology NAS for enterprise use that boosts the performance of I/O sensitive applications, such as databases, virtual machines, or online transaction processing (OLTP). Featuring a 12-core CPU and high-speed network connection, FS3600 delivers over 195,000 iSCSI 4K random write IOPS1 to satisfy enterprise demand for high-speed infrastructure.
Fully certified storage virtualization solutions
Synology iSCSI storage fully supports most virtualization solutions to enhance work efficiency with easy management interface. VMware vSphere 6 and VAAI integration helps offload storage operations and optimizes computation efficiency. Windows Offloaded Data Transfer (ODX) speeds up data transfer and migration rate. OpenStack Cinder support turns your Synology NAS into a block-based storage component.
Real-time collaboration on your private cloud
Synology Office is a collaboration package combining the convenience and usability of the public cloud with private cloud privacy and security. It enables seamless collaboration on documents and spreadsheets in a protected environment.
Next-generation file system for better data protection
The Btrfs file system introduces advanced storage technologies and optimized snapshots to prevent data corruption and reduce maintenance overheads. It offers flexible, efficient data protection and recovery tools while ensuring high-level data integrity.
- Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
- Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
- File- or folder-level data restoration accelerates data recovery and provides more flexibility for businesses
- Automatic file self-healing detects and recovers corrupted files without user intervention
| Opslagmedia | |
| Ondersteunde opslagstationinterfaces | SATA III, Serial Attached SCSI (SAS) |
| RAID support | Ja |
| Hot-swap drive bays | Ja |
| Ondersteunde bestandsystemen | BTRFS, FAT, HFS+, NTFS, exFAT, ext3, ext4 |
| Opslagdrives ge‹nstalleerd | Nee |
| Aantal storage drives ondersteund | 24 |
| Ge‹nstalleerde opslag-drive | Nee |
| Ondersteunde types opslag-drives | HDD & SSD |
| Processor | |
| Processorfabrikant | Intel |
| Processorfamilie | Intel© Xeon© D |
| Processormodel | D-1567 |
| Frequentie van processor | 2,1 GHz |
| Maximale turbofrequentie van processor | 2,7 GHz |
| Aantal processorkernen | 12 |
| Processor aantal threads | 24 |
| Processor cache | 18 MB |
| L3 cache | 18 MB |
| CPU configuratie (max) | 1 |
| PCI Express configuraties | 1x16, 1x4, 1x8 |
| PCI Express slots versie | 2.0, 3.0 |
| Processor cache type | L3 |
| Processorcode | SR2M3 |
| Codenaam processor | Broadwell |
| Processor lithografie | 14 nm |
| Processor operating modes | 64-bit |
| Verpakkingsgrootte processor | 37.5 x 37.5 mm |
| Processorserie | Intel Xeon D-1500 |
| Processor socket | BGA 1667 |
| Schaalbaarheid | 1S |
| Stepping | Y0 |
| Thermal Design Power (TDP) | 65 W |
| Maximaal intern geheugen ondersteund door processor | 128 GB |
| Conflictvrije processor | Ja |
| Geheugen | |
| Intern geheugentype | DDR4 |
| Ondersteund maximum RAM | 128 GB |
| Geheugenslots | 4 |
| Intern geheugen | 16 GB |
| Geheugen form factor | DIMM |
| Netwerk | |
| Ethernet LAN | Ja |
| Ethernet LAN, data-overdrachtsnelheden | 10,100,1000,10000 Mbit/s |
| iSCSI support | Ja |
| Ondersteunde netwerkprotocollen | SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPNT, L2TP) |
| Dynamic DNS (DDNS) | Ja |
| Poorten & interfaces | |
| USB-poort | Ja |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 2 |
| Aantal Ethernet LAN (RJ-45)-poorten | 6 |
| Design | |
| Type behuizing | Rack (2U) |
| Type koeling | Actief |
| Kleur van het product | Zwart |
| Aantal ventilatoren | 4 ventilator(en) |
| Ventilator diameter | 8 cm |
| Prestatie | |
| Soort | NAS |
| Apparaatklasse | Kleine & middelgrote bedrijven |
| Backup-functie | Ja |
| Back-up-eigenschappen | Cloud, USB-stick |
| Geluidsniveau | 57 dB |
| Energie | |
| Vermogenstoevoer locatie | Ingebouwd |
| Capaciteit voedingsunit (PSU) | 500 W |
| Aantal voedingen | 1 |
| Redundante voeding | Ja |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Gewicht en omvang | |
| Breedte | 482 mm |
| Diepte | 724 mm |
| Hoogte | 88 mm |
| Gewicht | 14,9 kg |
| Technische details | |
| Duurzaamheidscertificaten | RoHS |
| Compliance certificates | RoHS |
| Processor speciale functies | |
| Ingebouwde opties beschikbaar | Ja |
| Enhanced Intel SpeedStep Technology | Ja |
| Execute Disable Bit | Ja |
| Idle States | Ja |
| Intel© 64 | Ja |
| Intel© Enhanced Halt State | Ja |
| Versie Intel© Secure Key Technology | 1,00 |
| Intel© Trusted Execution Technology | Ja |
| Intel© TSX-NI | Ja |
| Versie Intel© TSX-NI | 1,00 |
| Intel© Virtualization Technology (VT-x) | Ja |
| Intel© Virtualization Technology for Directed I/O (VT-d) | Ja |
| Intel© VT-x with Extended Page Tables (EPT) | Ja |
| Intel© AES New Instructions (Intel© AES-NI) | Ja |
| Intel© Hyper Threading Technology (Intel© HT Technology) | Ja |
| Intel© OS Guard | Ja |
| Intel© Secure Key | Ja |
| Intel© Turbo Boost Technology | 2.0 |
| Maximaal aantal PCI Express-lijnen | 32 |
| Thermal Monitoring Technologies | Ja |
| UART | Ja |
| Geheugentypen ondersteund door processor | DDR3-SDRAM, DDR4-SDRAM |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 35 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 95 procent |
| Temperatuur bij opslag | -20 - 60 øC |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 84714100 |
| Overige specificaties | |
| ARK ID processor | 93356 |
| Warranty | |
| Base Warranty | Non Non |
