Hdmi Extender Over Cat5e/6 -4k 60hz 200ft/60m Hdmi 2.0
ITCurry #: 7564C192 | Article #: 4K50IC-EXTEND-HDMI-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Extend a 4K 60Hz HDMI signal over CAT6/6A cabling for distances of up to 200ft (60m) with Power over Cable
The HDMI Extender is designed to transmit visually lossless and low latency 4K 60Hz video and 7.1 channel audio up to 200 feet (60 meters) over a single network cable.
4K 60Hz Resolution
This HDMI over CAT5e extender is HDMI 2.0 compliant and supports up to 4K 60Hz resolutions, HDR, HDCP 2.2, DTS, and Dolby Digital audio. This makes it suitable for high-quality video and audio transmission over long distances.
Power-Over-Cable
The extender features Power-over-Cable (PoC) technology, allowing the included power adapter to connect only to the transmitter while providing power to both the transmitter and receiver through the CAT5e/6 cable. This feature reduces the need for additional power sources at the receiver end.
Versatile Installation Options
A point-to-point connection uses a single CAT6/5e cable and requires no drivers, software, or IP configuration, significantly reducing setup time. The HDMI extender can be mounted on a wall, ceiling, or the underside of a table using the included brackets, offering versatile professional installation options. The HDMI extender offers a longer range than HDMI cables, and Ethernet cables are easier to run in walls, behind furniture, or through cable trays. Its compact form factor makes it ideal for boardrooms, digital signage, trade shows, and classrooms.
The StarTech.com Advantage
| Kenmerken | |
| Soort | AV-zender & ontvanger |
| Maximum resolutie | 3840 x 2160 Pixels |
| Ondersteundende kabel types | Cat5e, Cat6 |
| Maximaal bereik | 60 m |
| Maximale refresh snelheid | 60 Hz |
| Audio-uitgangskanalen | 7.1 kanalen |
| Ondersteunde grafische resoluties | 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1440 x 900, 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 1440, 2048 x 1152, 2048 x 1536 (QXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 2560 x 1920, 2560 x 2048 |
| HDCP | Ja |
| Materiaal | Metaal |
| Rack-montage | Nee |
| HDCP versie | 2.2 |
| Kleur van het product | Zwart |
| Poorten & interfaces | |
| Connectiviteitstechnologie | Bedraad |
| RJ-45 invoer ports | 1 |
| RJ-45 uitgang ports | 1 |
| HDMI in | 1 |
| Aantal HDMI-uitgangen | 1 |
| HDMI versie | 2.0 |
| Aantal USB-aansluitingen | 1 |
| USB-connectortype | USB Type-C |
| Energie | |
| Type stroombron | USB |
| AC-ingangsspanning | 100 - 240 V |
| Stroom | 0.3 A |
| Bedrijfsspanning (zender) | 5 V |
| Output current | 2 A |
| Bedrijfsspanning (ontvanger) | 5 V |
| Stroomverbruik (typisch) | 10 W |
| USB Power Delivery (USB PD) | Ja |
| Externe adapter | Ja |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -20 - 60 øC |
| Temperatuur bij opslag | -30 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 0 - 90 procent |
| Gewicht en omvang | |
| Receiver afmetingen (B x D x H) | 40 x 67 x 23 mm |
| Receiver gewicht | 92 g |
| Transmitter afmetingen (WxDxH) | 40 x 67 x 23 mm |
| Transmitter gewicht | 92 g |
| Verpakking | |
| Breedte verpakking | 150 mm |
| Diepte verpakking | 117 mm |
| Hoogte verpakking | 77 mm |
| Gewicht verpakking | 364 g |
| Inhoud van de verpakking | |
| Inclusief AC-adapter | Ja |
| Inbegrepen soorten voedingsstekkers | ANZ, EU, NA, UK |
| Snelstartgids | Ja |
| Montagebeugels meegeleverd | Ja |
| Technische details | |
| Certificaten van naleving | Federal Communications Commission (FCC), RoHS |
| Logistieke gegevens | |
| (Buitenste) hoofdverpakking breedte | 430 mm |
| (Buitenste) hoofdverpakking lengte | 330 mm |
| (Buitenste) hoofdverpakking hoogte | 380 mm |
| Hoeveelheid per (buitenste) hoofdverpakking | 30 stuk(s) |
| Warranty | |
| Base Warranty | Non Non |
