Product Informatie
The XCubeNAS series is a next generation, high performance, efficiency and security NAS system which is designed for SMB and enterprise applications. The XCubeNAS operating system is the brand new, and entirely reimagined QSM 3 brings the enterprise level features into the Workgroup and SMB storage. QSM 3 supports comprehensive enterprise-level storage features including SSD caching, thin provisioning, auto-tiering, data deduplication and data compression that transforms the efficiency of every resource to bring you commercial value.
| Opslagmedia | |
| Opslag schijf-interface | SATA III |
| Ondersteunde opslagstationinterfaces | SATA III |
| Opslag schijfgrootte | 2.5/3.5" |
| Opslagschijf afmetingen ondersteund | 2.5,3.5" |
| Maximaal ondersteunde opslagcapaciteit | 128 TB |
| RAID support | Ja |
| Soorten RAID | 0, 1, 5, 6, 10, 60, JBOD |
| Hot-swap drive bays | Ja |
| Opslagdrives ge‹nstalleerd | Nee |
| Aantal storage drives ondersteund | 8 |
| Ge‹nstalleerde opslag-drive | Nee |
| Ondersteunde types opslag-drives | HDD & SSD |
| Processor | |
| Processorfabrikant | Intel |
| Processorfamilie | Intel© Celeron© |
| Processormodel | G3930 |
| Frequentie van processor | 2,9 GHz |
| Aantal processorkernen | 2 |
| Bus type | DMI3 |
| CPU configuratie (max) | 1 |
| Conflictvrije processor | Ja |
| Geheugen | |
| Intern geheugentype | DDR4 |
| Ondersteund maximum RAM | 32 GB |
| Geheugenslots | 2 |
| Intern geheugen | 8 GB |
| Geheugen form factor | SO-DIMM |
| Flash memory | 8000 MB |
| Netwerk | |
| Ethernet LAN | Ja |
| Ethernet LAN, data-overdrachtsnelheden | 1000 Mbit/s |
| Wifi | Nee |
| Jumbo Frames ondersteuning | Ja |
| iSCSI support | Ja |
| Wake-on-LAN | Ja |
| Verbindingsaggregatie | Ja |
| Dynamic DNS (DDNS) | Ja |
| Poorten & interfaces | |
| USB-poort | Ja |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 5 |
| Aantal HDMI-poorten | 1 |
| Aantal Ethernet LAN (RJ-45)-poorten | 4 |
| Design | |
| Type behuizing | Tower |
| Type koeling | Actief |
| Kleur van het product | Grijs |
| Land van herkomst | Taiwan |
| Prestatie | |
| Soort | NAS |
| Apparaatklasse | Kleine & middelgrote bedrijven |
| Backup-functie | Ja |
| Back-up-eigenschappen | Cloud, iSCSI LUN |
| Ondersteunt meerdere talen | Ja |
| Web-gebaseerd management | Ja |
| Ondersteunde beveiligingsalgoritmen | 256-bit AES, FIPS 140-2 |
| Access Control List (ACL) | Ja |
| Ingebouwde ftp-server | Ja |
| Netwerktijdprotocol (NTP) klant | Ja |
| Systeemlog | Ja |
| Hot-spare | Ja |
| S.M.A.R.T. support | Ja |
| Software | |
| Inclusief besturingssysteem | QNAP Storage Manager |
| Operating systeem versie | 3 |
| Ondersteunt Windows | Ja |
| Ondersteunt Linux | Ja |
| Ondersteunt Mac-besturingssysteem | Ja |
| Energie | |
| Vermogenstoevoer locatie | Ingebouwd |
| Capaciteit voedingsunit (PSU) | 200 W |
| Aantal voedingen | 1 |
| Redundante voeding | Nee |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Gewicht en omvang | |
| Breedte | 310 mm |
| Diepte | 235 mm |
| Hoogte | 177 mm |
| Gewicht | 4,8 kg |
| Processor speciale functies | |
| Ingebouwde opties beschikbaar | Nee |
| Enhanced Intel SpeedStep Technology | Ja |
| Execute Disable Bit | Ja |
| Idle States | Ja |
| Intel© 64 | Ja |
| Intel© Clear Video-technologie | Ja |
| Intel© Enhanced Halt State | Ja |
| Versie Intel© Identity Protection Technology | 1,00 |
| Versie Intel© Secure Key Technology | 1,00 |
| Intel© Stable Image Platform Program (SIPP) | Nee |
| Versie Intel© Stable Image Platform Program (SIPP) | 0,00 |
| Intel© Trusted Execution Technology | Nee |
| Intel© TSX-NI | Nee |
| Versie Intel© TSX-NI | 0,00 |
| Intel© Virtualization Technology (VT-x) | Ja |
| Intel© Virtualization Technology for Directed I/O (VT-d) | Ja |
| Intel© VT-x with Extended Page Tables (EPT) | Ja |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 20 - 80 procent |
| Temperatuur bij opslag | -10 - 50 øC |
| Luchtvochtigheid bij opslag | 10 - 90 procent |
| Certificaten | |
| Certificering | CE, FCC, BSMI, VCCI, RCM, KCC, SASO, EAC |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 84714100 |
| Warranty | |
| Base Warranty | Non Non |
