Transceiver 40gbe Qsfp+mpo 850nm 150m Ddmi
ITCurry #: Q6253270 | Article #: 980-9I426-00BM00-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Mellanox MMA1B00-B150D Mellanox Transceiver 40GbE QSFP+ MPO 850nm SR4 up to 150m DDMI
Mellanox MMA1B00-B150D is a 4-channel, pluggable, QSFP+, VCSEL-based (Vertical Cavity Surface Emitting Laser) optical transceiver designed for up to 150m reach in 40Gb/s Ethernet networks operating at 4x10.3125Gb/s. This transceiver incorporates Mellanox integrated circuit technology, which combines high performance at low power. The transceiver operates over parallel multi-mode fiber (MMF), using a nominal wavelength of 850nm, and is SFF-8436 compliant. The MMA1B00-B150D transceiver has a standard QSFP+ connector on the electrical side towards the host system for power, control/monitoring and high-speed data. The optical interface is composed of four optical channels/fibers in each direction, intended for a parallel MMF cable via a standard MPO connector. The transceiver can operate 10.3125Gb/s without retiming. The transceiver provides digital diagnostic monitoring of supply voltage, temperature, transmit/receive power, and VCSEL bias. Rigorous production testing ensures the best out-of-the-box installation experience, performance, and durability.
| Warranty | |
| Base Warranty | Non Non |
| Prestatie | |
| SFP transceiver type | Vezel-optiek |
| Maximale overdrachtssnelheid van gegevens | 40000 Mbit/s |
| Soort aansluiting | QSFP+ |
| Multi-mode glasvezelkabel (MMF) ondersteund | Ja |
| Maximaal bereik | 150 m |
| Golflengte | 850 nm |
| Netwerkstandaard | IEEE 802.3 |
| Energie | |
| Ingangsspanning | 3.6 V |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 70 øC |
| Temperatuur bij opslag | -40 - 85 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 85 procent |
| Gewicht en omvang | |
| Breedte | 18,3 mm |
| Diepte | 118 mm |
| Hoogte | 8,5 mm |
| Technische details | |
| Certificaten van naleving | RoHS |
