Product Informatie
ConnectX-6 VPI Card 200Gb/s InfiniBand & Ethernet Adapter Card
ConnectX-6 Virtual Protocol Interconnect (VPI) cards are a groundbreaking addition to the ConnectX series of industry-leading network adapter cards. Providing two ports of 200Gb/s for InfiniBand and Ethernet connectivity, sub-600ns latency and 215 million messages per second, ConnectX-6 VPI cards enable the highest performance and most flexible solution aimed at meeting the continually growing demands of data center applications. In addition to all the existing innovative features of past versions, ConnectX-6 cards offer a number of enhancements to further improve performance and scalability.
ConnectX-6 VPI supports HDR, HDR100, EDR, FDR, QDR, DDR and SDR InfiniBand speeds as well as 200, 100, 50, 40, 25, and 10Gb/s Ethernet speeds.
| Poorten & interfaces | |
| Connectiviteitstechnologie | Bedraad |
| Hostinterface | PCI Express |
| Interface | Fiber |
| Fibre channel-poorten | 2 |
| Vezel-optische connector | QSFP56 |
| PCI versie | 4.0 |
| PCI Card form factor | Half-height (low-profile) |
| Netwerk | |
| Maximale overdrachtssnelheid van gegevens | 200000 Mbit/s |
| Design | |
| Component voor | Server/werkplaats |
| Kleur van het product | Groen |
| Intern | Ja |
| Vormfactor | OCP 3.0 |
| Warranty | |
| Base Warranty | Non Non |
| Technische details | |
| Certificaten van naleving | RoHS |
