Ptmount Thermal S15/s16 50 Mk L65 (25o)- Pure White
ITCurry #: N5993388 | Article #: MX-O-SMA-TP-T119-
                                    SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
- Manually adjustable dome mount with integrated thermal sensor module
- Highly sensitive thermal image sensor: NETD typ. 50 mK (equal to 0.05 °C, or 0.09 °F), IR range 7.5 to 13.5 micrometer, uncooled micro bolometer, up to 9 frames per second, MTBF > 80.000 hours
- Features three axes that allow it to compensate for sideway tilt and to re-align the image horizon horizontally when mounted to a wall
- Concealed cabling (2 m sensor cable included), weatherproof from -30 to +60°C/-22 to 140°F
- Robust housing (PBT, color: white or black), IP66, IK04
Note:
The thermal sensor modules are connected to the DualFlex camera housing, which is available as an option, using the two-meter sensor cable that is already connected to the PTMount-Thermal.
| Kenmerken | |
| Soort | Sensorunit |
| Ondersteuning voor plaatsing | Universeel |
| Compatibiliteit | DualFlex S15/S16 |
| Kleur van het product | Wit |
| Internationale veiligheidscode (IP) | IP66 |
| Beeldsensor | |
| Megapixels | 6 MP |
| Resolutie | 336 x 252 Pixels |
| Kijkhoek, horizontaal | 25ø |
| Kijkhoek, verticaal | 19ø |
| Poorten & interfaces | |
| Connectiviteitstechnologie | Bedraad |
| Gewicht en omvang | |
| Snoerlengte | 2 m |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -30 - 60 øC |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85299020 |
| Warranty | |
| Base Warranty | Non Non |
