Product Informatie
The ThinkSystem SE350 is a purpose-built server that is half the width and significantly shorter than a traditional server, making it ideal for deployment in tight spaces. It can be mounted on a wall, stacked on a shelf or mounted in a rack. The ThinkSystem SE350 puts increased processing power, storage and network closer to where data is generated, allowing actions resulting from the analysis of that data to take place more quickly.
This product guide provides essential pre-sales information to understand the ThinkSystem SE350 edge server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SE350 and consider its use in IT solutions.
Introduction
The ThinkSystem SE350 is a purpose-built server that is half the width and significantly shorter than a traditional server, making it ideal for deployment in tight spaces. It can be mounted on a wall, stacked on a shelf or mounted in a rack. The ThinkSystem SE350 puts increased processing power, storage and network closer to where data is generated, allowing actions resulting from the analysis of that data to take place more quickly.
Suggested uses: edge computing (IoT, AI, machine learning), retail, video security, inventory management, building control, telecommunications, manufacturing, distribution
Did you know?
Customers looking for computing solutions at the edge of their networks often have to compromise -- to use either datacenter-class equipment which is too large and power hungry, or PC based equipment which can't run their enterprise level applications. The ThinkSystem SE350 fits the space between those two extremes. Its compact design, low power usage, and high performance are just the right combination for edge locations. The SE350 can be wall mounted, stacked on a shelf or installed in a rack. It is also designed to operate in rugged environments, up to 55°C.
| Processor | |
| Processorfabrikant | Intel |
| Processorfamilie | Intel© Xeon© D |
| Processormodel | D-2123IT |
| Frequentie van processor | 2,2 GHz |
| Maximale turbofrequentie van processor | 3 GHz |
| Aantal processorkernen | 4 |
| Processor cache | 8 MB |
| Aantal ge‹nstalleerde processoren | 1 |
| Thermal Design Power (TDP) | 60 W |
| Processor socket | BGA 2518 |
| Processor lithografie | 14 nm |
| Processor aantal threads | 8 |
| Processor operating modes | 64-bit |
| Stepping | M1 |
| Bus type | UPI |
| Codenaam processor | Skylake |
| Maximaal intern geheugen ondersteund door processor | 512 GB |
| Geheugentypen ondersteund door processor | DDR4-SDRAM |
| Klokgeheugen-snelheden ondersteund door processor | 2400 MHz |
| Execute Disable Bit | Ja |
| Idle States | Ja |
| Thermal Monitoring Technologies | Ja |
| Maximaal aantal PCI Express-lijnen | 32 |
| Ondersteunde instructie sets | AVX 2.0 |
| Processorcode | SR3ZW |
| Schaalbaarheid | 1S |
| Ingebouwde opties beschikbaar | Ja |
| Conflictvrije processor | Ja |
| Geheugen | |
| Intern geheugen | 16 GB |
| Intern geheugentype | DDR4-SDRAM |
| Geheugenslots | 4 |
| ECC | Ja |
| Kloksnelheid geheugen | 2666 MHz |
| Geheugenlayout | 1 x 16 GB |
| Maximum intern geheugen | 256 GB |
| Opslagmedia | |
| Totale opslagcapaciteit | 480 GB |
| Aantal ge‹nstalleerde SSD's | 1 |
| SSD capaciteit | 480 GB |
| SSD interfaces | SATA |
| SSD-formaat | M.2 |
| RAID support | Ja |
| Soorten RAID | 0, 1, 5, 10 |
| Soort optische drive | Nee |
| Grafisch | |
| Ingebouwde grafische adapter | Ja |
| On-board graphics adapter model | Matrox G200 |
| Netwerk | |
| Ethernet LAN | Ja |
| Bekabelingstechnologie | 10/100/1000Base-T(X) |
| Ethernet interface type | 10 Gigabit Ethernet, Gigabit Ethernet |
| Poorten & interfaces | |
| Aantal USB 2.0-poorten | 2 |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 2 |
| VGA (D-Sub)poort(en) | 1 |
| Design | |
| Type behuizing | Rack (1U) |
| Kleur van het product | Zwart |
| Prestatie | |
| BIOS type | UEFI |
| Trusted Platform Module (TPM) | Ja |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Compatibele besturingssystemen | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi |
| Processor speciale functies | |
| CPU configuratie (max) | 1 |
| Enhanced Intel SpeedStep Technology | Ja |
| Intel© Virtualization Technology for Directed I/O (VT-d) | Ja |
| Intel© Hyper Threading Technology (Intel© HT Technology) | Ja |
| Intel© Turbo Boost Technology | 2.0 |
| Intel© AES New Instructions (Intel© AES-NI) | Ja |
| Intel© Trusted Execution Technology | Ja |
| Intel© Enhanced Halt State | Ja |
| Intel© VT-x with Extended Page Tables (EPT) | Ja |
| Intel© Secure Key | Ja |
| Intel© TSX-NI | Ja |
| Intel© OS Guard | Ja |
| Intel© Software Guard Extensions (Intel© SGX) | Nee |
| Intel© 64 | Ja |
| Versie Intel© Secure Key Technology | 1,00 |
| Intel© Virtualization Technology (VT-x) | Ja |
| Versie Intel© TSX-NI | 1,00 |
| Intel© QuickAssist-technologie | Nee |
| ARK ID processor | 136429 |
| Energie | |
| Redundante voeding | Ja |
| Aantal ge‹nstalleerde redundante voedingen | 2 |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 5 - 45 øC |
| Temperatuur bij opslag | -40 - 60 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 8 - 90 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 84714100 |
| Gewicht en omvang | |
| Breedte | 209 mm |
| Diepte | 376 mm |
| Hoogte | 43 mm |
| Gewicht | 3,75 kg |
| Warranty | |
| Base Warranty | Non Non |
