Specifications |
Type / Form Factor |
Intel Xeon Gold 5512U (5th Gen) |
Number of Cores |
28-core |
Number of Threads |
56 threads |
Cache |
52.5 MB |
Cache Memory Details |
Smart Cache - 52.5 MB |
Processor Qty |
1 |
Clock Speed |
2.1 GHz |
Max Turbo Speed |
3.7 GHz |
Compatible Processor Socket |
FCLGA4677 Socket |
Manufacturing Process |
7 nm |
Thermal Design Power |
185 W |
Thermal Specification |
98 °C |
PCI Express Revision |
5.0 |
PCI Express Lanes Qty |
80 |
Architecture Features |
Hyper-Threading Technology, Execute Disable Bit capability, Intel Virtualization Technology, Intel 64 Technology, Intel Trusted Execution Technology, Intel Turbo Boost Technology 2.0, Intel AES New Instructions (AES-NI), Intel Virtualization Technology for Directed I/O (VT-d), Intel VT-x with Extended Page Tables (EPT), Intel QuickAssist Technology, Intel OS Guard, Intel Software Guard Extensions (SGX), Intel Speed Shift Technology, Mode-based Execute Control (MBE), Intel Run Sure Technology, Intel Boot Guard, Intel Deep Learning Boost (DL Boost), Intel Resource Director Technology (RDT), Intel Speed Select technology - Core Power, Intel Speed Select technology - Turbo Frequency, Intel Control-Flow Enforcement Technology, Intel Total Memory Encryption, Intel Platform Firmware Resilience Support, Intel Crypto Acceleration, Instruction Set 64-bit, Intel Data Streaming Accelerator (DSA), Intel QuickAssist Software Acceleration, 128 GB maximum Enclave Page Cache (EPC) size for Intel SGX, Activating Intel On Demand Feature, Intel Advanced Matrix Extensions (AMX), Intel In-memory Analytics Accelerator (IAA) |
|
