Xeon Gold Processor 5318y 2.10 GHz 36MB Cache - Tray
ITCurry #: 2730D183 | Article #: CD8068904656703-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Cache
CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.
Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.
Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel® Crypto Acceleration
Intel® Crypto Acceleration reduces the performance impact of pervasive encryption and increases the performance of encryption-intensive workloads including SSL web serving, 5G infrastructure, and VPN/firewalls.
Intel® Software Guard Extensions (Intel® SGX)
Intel® Software Guard Extensions (Intel® SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications’ sensitive routines and data. Intel® SGX provides developers a way to partition their code and data into CPU hardened trusted execution environments (TEE’s).
Intel® Speed Select Technology – Core Power
Enables flexibility for workloads that benefit from higher base frequency on a subset of the processor’s cores. While the max turbo frequency across the cores remain constant across the cores, a subset of the cores can be assigned as to run at a higher base frequency than specified, while the other cores run at lower base frequency.
Intel® Speed Select Technology – Turbo Frequency
Enables flexibility for workloads that benefit from higher turbo frequency on a subset of the processor’s cores. While the base frequency remains constant across the cores, a subset of the cores can be assigned to run at a higher turbo frequency than specified, while the other cores run at lower turbo frequency.
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Instruction Set Extensions
Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).
Intel® Run Sure Technology
Intel® Run Sure Technology, includes advanced RAS (reliability, availability and serviceability) features that deliver high reliability and platform resiliency, to maximize uptime of servers running mission-critical workloads.
Intel® Total Memory Encryption
TME – Total Memory Encryption (TME) helps protect data against exposure via physical attack on memory, such as cold-boot attacks.
Max # of UPI Links
Intel® Ultra Path Interconnect (UPI) links are a high speed, point-to-point interconnect bus between the processors, delivering increased bandwidth and performance over Intel® QPI.
# of AVX-512 FMA Units
Intel® Advanced Vector Extensions 512 (AVX-512), new instruction set extensions, delivering ultra-wide (512-bit) vector operations capabilities, with up to 2 FMAs (Fused Multiply Add instructions), to accelerate performance for your most demanding computational tasks.
Intel® Resource Director Technology (Intel® RDT)
Intel® RDT brings new levels of visibility and control over how shared resources such as last-level cache (LLC) and memory bandwidth are used by applications, virtual machines (VMs) and containers.
Intel® Speed Select Technology - Performance Profile
A capability to configure the processor to run at three distinct operating points.
Intel® Speed Select Technology - Base Frequency
Enables users to increase guaranteed base frequency on certain cores (high priority cores) in exchange for lower base frequency on remaining cores (low priority cores). Improves overall performance by boosting frequency on critical cores.
Intel® Volume Management Device (VMD)
Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.
Intel® Optane™ Persistent Memory Supported
Intel® Optane™ persistent memory is a revolutionary tier of non-volatile memory that sits between memory and storage to provide large, affordable memory capacity that is comparable to DRAM performance. Delivering large system-level memory capacity when combined with traditional DRAM, Intel Optane persistent memory is helping transform critical memory constrained workloads – from cloud, databases, in-memory analytics, virtualization, and content delivery networks.
Mode-based Execute Control (MBEC)
Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.
Intel® Transactional Synchronization Extensions
Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software.
| Processor | |
| Processorfabrikant | Intel |
| Processorgeneratie | 3e generatie Intel© Xeon© schaalbaar |
| Processormodel | 5318Y |
| Basisfrequentie processor | 2,1 GHz |
| Processorfamilie | Intel© Xeon© Gold |
| Aantal processorkernen | 24 |
| Processor socket | LGA 4189 |
| Component voor | Server/werkplaats |
| Processor lithografie | 10 nm |
| Processorserie | Intel Xeon Gold 5000 Series |
| Processor aantal threads | 48 |
| Systeembus | 11,2 GT/s |
| Processor operating modes | 64-bit |
| Maximale turbofrequentie van processor | 3,4 GHz |
| Kernen met hoge prioriteit | 8 |
| Kernfrequentie met hoge prioriteit | 2,3 GHz |
| Kernen met lage prioriteit | 16 |
| Kernfrequentie met lage prioriteit | 1,8 GHz |
| Processor cache | 36 MB |
| Thermal Design Power (TDP) | 165 W |
| Box | Nee |
| Inclusief koeler | Nee |
| Codenaam processor | Ice Lake |
| ARK ID processor | 215271 |
| Geheugen | |
| Maximaal intern geheugen ondersteund door processor | 6 TB |
| Geheugentypen ondersteund door processor | DDR4-SDRAM |
| Klokgeheugen-snelheden ondersteund door processor | 2933 MHz |
| Geheugen kanaal | Achtkanaals |
| ECC | Ja |
| Grafisch | |
| Ingebouwde grafische adapter | Nee |
| Aparte grafische adapter | Nee |
| On-board graphics adapter model | Niet beschikbaar |
| Discreet grafische adapter model | Niet beschikbaar |
| Kenmerken | |
| Execute Disable Bit | Ja |
| Marktsegment | Server |
| Maximaal aantal PCI Express-lijnen | 64 |
| PCI Express slots versie | 4.0 |
| Ondersteunde instructie sets | SSE4.2, AVX, AVX 2.0, AVX-512 |
| Schaalbaarheid | 2S |
| Ingebouwde opties beschikbaar | Ja |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) | G178966 |
| Processor speciale functies | |
| Intel© Hyper Threading Technology (Intel© HT Technology) | Ja |
| Intel© Turbo Boost Technology | 2.0 |
| Intel© AES New Instructions (Intel© AES-NI) | Ja |
| Intel© Trusted Execution Technology | Ja |
| Intel© Speed Shift-technologie | Ja |
| Intel© Transactional Synchronization Extensions | Ja |
| Intel© Total Memory Encryption | Ja |
| Intel© Crypto Acceleration | Ja |
| Ondersteuning voor Intel© Platform Firmware Resilience | Ja |
| Ondersteuning voor maximale enclavegrootte voor Intel© SGX | 64 GB |
| Intel© VT-x with Extended Page Tables (EPT) | Ja |
| Intel© Software Guard Extensions (Intel© SGX) | Ja |
| Intel© 64 | Ja |
| Intel© Virtualization Technology (VT-x) | Ja |
| Intel© Virtualization Technology for Directed I/O (VT-d) | Ja |
| AVX-512 Fused Multiply-Add (FMA) eenheden | 2 |
| Intel© Deep Learning Boost (Intel© DL Boost) on CPU | Ja |
| Intel© Speed Select-technologie - Prestatieprofiel (Intel© SST-PP) | Ja |
| Intel© Resource Director-technologie (Intel© RDT) | Ja |
| Intel© Volume Management Device (VMD) | Ja |
| Intel© Run Sure-technologie | Ja |
| Mode-based Execute Control (MBE) | Ja |
| Intel© OptaneT DC Persistent Memory ondersteunt | Ja |
| Warranty | |
| Base Warranty | Non Non |
| Eisen aan de omgeving | |
| Tcase | 87 øC |
| Technische details | |
| Doelgroep | Cloud Computing |
| Lanceringsdatum | Q2'21 |
| Status | Launched |
| Ondersteunde geheugen types | DDR4-SDRAM |
| Geheugensnelheid (max) | 2933 MHz |
| Aantal UPI-koppelingen | 3 |
| Onderhoudsstatus | Baseline Servicing |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85423119 |
| Gewicht en omvang | |
| Verpakkingsgrootte processor | 77.5 x 56.5 mm |
| Overige specificaties | |
| Maximum intern geheugen | 6 TB |
