OfficeConnect 1420 5G Switch, (5) RJ-45 autosensing 10/100/1000 ports
ITCurry #: 1171QM37 | Article #: JH327A#ABB-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The HPE 1420 Switch Series consists of unmanaged Gigabit Ethernet switches for small businesses and others looking for plug-and-play basic Layer 2 connectivity for their network, including low-cost PoE+ and 10GbE uplink models. The HPE 1420 Switch Series has four models: 16-port 10/100/1000, 24-port 10/100/1000 with two SFP Gigabit ports, 24-port 10/100/1000 ports of which 12 are PoE+ enabled (124 W PoE budget), and 24-port 10/100/1000 with two SFP+ 10GbE ports.
Features
High-performance GbE Layer 2 Switching, Cost-effective and Easy to Deploy
- The HPE 1420 Switch Series offers small businesses and others Layer 2 Gigabit Ethernet switching with unmanaged affordability and plug-and-play simplicity.
- Gigabit Ethernet is the most recommended and deployed networking technology today, delivering 10 times more performance than Fast Ethernet.
- Unmanaged switches are the most economical offerings, ideal for locations needing only basic Layer 2 switching in a flat single tier network.
Model Choices to Meet Most Design Needs for Basic Layer 2 Networking
- The HPE 1420 Switch Series has four models to choose from, all with Gigabit performance but offering different uplink options. Consider the 16-port model for locations needing fewer connections and one of the 24-port models where more connectivity is required.
- The 1420-24G-2SFP model with SFP uplinks is ideal where Gigabit fiber is required, while the 1420-24G-2SFP+ 10G Uplink model with SFP+ uplinks is available where 10GbE is needed now or in the future.
- Anticipate the installation of IP voice, wireless Access points, or video surveillance cameras by deploying Power over Ethernet (PoE). Choose the PoE+ model for highly cost-effective PoE deployments.
- All 1420 Switch Series models are fanless for silent operation, usable in office settings around workers. Units have internal power supplies with power-cord plug-in simplicity.
- Units can be deployed for desktop operation or can be rack mounted.
Automated Features for Hands-off Operation
- All HPE 1420 Switch Series models are plug-and-play with zero configuration and no required ongoing administration.
- The switch series has the company's only unmanaged PoE model, with fully automated support for powering compatible IP phones, video surveillance cameras or wireless Access Points.
- The HPE 1420-24G-2SFP+ 10G Uplink Switch requires no configuration beyond installation of optional 10GbE transceivers to achieve 10GbE speeds. Alternatively, use today with Gigabit SFP transceivers if higher performance is merely a future requirement.
- IEEE 802.1p prioritization and other QoS features automate the preferred handling of high priority traffic, including Differentiated Services Code Point (DSCP) set priorities.
- The 1420 Switch Series supports Jumbo packets to improve the performance of large data transfers.
Cost-effective Ownership for Now and into the Future
- The HPE 1420 Switch Series offers a cost-effective upgrade path to next-generation 10GbE networks to reduce performance bottlenecks when connecting to storage and servers.
- The switch series includes PoE+ options to power IP devices without the cost of additional cabling for power.
- Green features include energy-efficient Ethernet IEEE 802.3az, auto-power down mode on idle ports, and power savings on short distance cables for low power consumption.
- Limited Lifetime Warranty.
| Beheerfuncties | |
| Switch type | Unmanaged |
| Switch-laag | L2 |
| Quality of Service (QoS) | Ja |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 5 |
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
| Netwerk | |
| Netwerkstandaard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| 10G support | Nee |
| Koperen ethernetbekabelingstechnologie | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Full duplex | Ja |
| Datastroombeheer | Ja |
| Auto MDI/MDI-X | Ja |
| Auto-sensing | Ja |
| Data-uitwisseling | |
| Switchingcapaciteit | 10 Gbit/s |
| Throughput | 7,4 Mpps |
| MAC-adrestabel | 2048 entries |
| Latentie (10-100 Mbps) | 3 æs |
| Latentie (1 Gbps) | 2,6 æs |
| Jumbo Frames ondersteuning | Ja |
| Packet buffergeheugen | 1 MB |
| Design | |
| Rack-montage | Ja |
| Stapelbaar | Ja |
| Vormfactor | 1U |
| Kleur van het product | Grijs |
| Energie | |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Stroomverbruik (typisch) | 3 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Nee |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 15 - 95 procent |
| Luchtvochtigheid bij opslag | 15 - 95 procent |
| Gewicht en omvang | |
| Breedte | 114,8 mm |
| Diepte | 80,8 mm |
| Hoogte | 26,9 mm |
| Gewicht | 300 g |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
