Networking Comware Switch 24P Multigigabit 100M/1G/2.5G/5G/10GBase-T PoE8 1 Slot 5600HI
ITCurry #: 1171AKM8 | Article #: S0S34A-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The HPE Networking Comware Switch Series 5600 HI delivers superior performance using multigigabit, PoE8, MACsec, AES 256 encryption, link flexibility, and scalability at the access layer of medium and large enterprise campus networks. Additional modules can be included for increased capacity. This series offers improved resiliency with DRNI and IRF, better reliability and performance in user quality of service (QoS), enhanced security with hardware-based MACsec and AAA authentication, impressive efficiency with dual redundant power supplies, embedded network management using smart management center (SmartMC) and enhanced network visibility using IMC.
What is new supporting point:
Smart management center (SmartMC) provides centralized network management and maintains dispersed network edge devices at no additional cost
iNQA measures network packet loss performance and provides visibility into real-time application performance and health
Industry-standard MACsec AES 256 support, higher MAC port binding, AAA authentications (including RADIUS authentication), and link group capacity for improved end-to-end network security
DRNI combines multiple physical switches into one virtual distributed-relay system for doubling aggregate bandwidth, faster forwarding, resiliency, and high availability
VXLAN and EVPN enable both isolation and greater scalability of L2/L3 overlay services and multicast
Multigigabit 100M/1/2.5/5/10G options with PoE8. Granular, higher throughput, and switching capacity of up to 600 Mpps and 1440 Gbps, higher traffic rates and improved network performance
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L3 |
| Quality of Service (QoS) | Ja |
| Traffic-classificatie | Ja |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 24 |
| Type basis-switching RJ-45 Ethernet-poorten | 2.5G Ethernet (100/1000/2500) |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 1 |
| Aantal USB Type-A-poorten | 1 |
| Aantal beheerpoorten | 1 stuk(s) |
| Netwerk | |
| 10G support | Ja |
| Koperen ethernetbekabelingstechnologie | 10BASE-T |
| Port mirroring | Ja |
| Full duplex | Ja |
| Data-uitwisseling | |
| Throughput | 240 Mpps |
| Packet buffergeheugen | 3 MB |
| Design | |
| Rack-montage | Ja |
| Stapelbaar | Ja |
| Vormfactor | 1U |
| Kleur van het product | Zwart, Grijs |
| Reset button | Ja |
| Prestatie | |
| Physical stacking (units) | 9 |
| Intern geheugen | 2048 MB |
| Flash memory | 1024 MB |
| Energie | |
| Stroombron | AC/DC |
| Vermogenstoevoer inclusief | Nee |
| AC-ingangsspanning | 90 - 264 V |
| AC-ingangsfrequentie | 50/60 Hz |
| DC voltage input | 36 - 72 V |
| Energieverbruik opmerking | Dual AC 2385W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Ja |
| Totaal Power over Ethernet (PoE)-budget | 90 W |
| Overige specificaties | |
| Latentie | < 5 us (1000Mb), < 3 us (10Gbps) <1.2 us (40Gbps) |
| Geheugen en processor | 2 GB SDRAM; packet buffer size: 3 MB, 1G flash |
| Aansluitingen | 24 x 100M/1G/2.5G/5G/10GBASE-T (PoE8) + 1 expansion slot |
| Prestatiebeheer | This switch series includes Smart Management Center (SmartMC) at no additional cost and combined with HPE Intelligent Management Center (IMC), provides both embedded network management and enhanced network visibility. |
| Gewicht (imperiaal) | 5,5 kg (12.1 lbs) |
| Afmetingen (B x D x H) (Brits) | 43,7 x 439,9 x 460 mm (1.72 x 17.3 x 18.1") |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -5 - 45 øC |
| Gewicht en omvang | |
| Breedte | 43,7 mm |
| Diepte | 440 mm |
| Hoogte | 460 mm |
| Gewicht | 5,5 kg |
| Warranty | |
| Base Warranty | Non Non |
