InfiniBand HDR/Ethernet 200GB 1-port QSFP56 MCX653105A-HDAT Pci-e 4 x16 Adapter
ITCurry #: 1171XV15 | Article #: P23664-B21-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Are you looking for extremely high-bandwidth and very low latency communications for your HPE Apollo System and HPE ProLiant DL rack mount server families? The HPE HDR InfiniBand and Ethernet adapters are designed for customers who deploy high performance computing (HPC) systems with their HPE ProLiant XL and HPE ProLiant DL Gen10 and Gen10 Plus servers in the data center. The HPE InfiniBand HDR/HDR100 and Ethernet adapters are available as stand up cards or in the OCP 3.0 form factor, equipped with 1 port or 2 ports. Combined with HDR InfiniBand switches, they deliver low latency and up to 200Gbps bandwidth, ideal for performance-driven server and storage clustering applications in HPC and enterprise data centers.
What is new supporting point:
The HDR InfiniBand and Ethernet adapters are now available in the OCP 3.0 form factor with support for HPE iLO shared network port in Ethernet mode.
The HDR InfiniBand and Ethernet adapters for HPE ProLiant Gen10 Plus servers are based on standard Mellanox ConnectX-6 technology.
| Poorten & interfaces | |
| Connectiviteitstechnologie | Bedraad |
| Hostinterface | PCI Express |
| Interface | Ethernet |
| Vezel-optische connector | QSFP56 |
| Netwerk | |
| Maximale overdrachtssnelheid van gegevens | 200 Mbit/s |
| Design | |
| Component voor | Server |
| Intern | Ja |
| Compatibele producten | HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy |
| Gewicht en omvang | |
| Breedte | 355,6 mm |
| Diepte | 609,6 mm |
| Hoogte | 254 mm |
| Gewicht | 230 g |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Overige specificaties | |
| Soort kabel | DAC and AOC |
| Aantal poorten | 1 |
| Gewicht (imperiaal) | 0,231 kg (0.509 lbs) |
| Afmetingen (B x D x H) (Brits) | 609,6 x 355,6 x 254 mm (24 x 14 x 10") |
| Type behuizing | Standup LP |
| Warranty | |
| Base Warranty | Non Non |
