Aruba Networking 8325-32C Power-to-Port Airflow 6 Fans 2 Power Supply Units Bundle
ITCurry #: 1171AKL7 | Article #: R9F67A-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The Aruba 8325 switch serves as both a campus (core and aggregation) and data center (Top of Rack) switch. This game-changing solution offers an innovative approach to dealing with network demands in the mobile, cloud and IoT era.
The Aruba 8325 is based on ArubaOS-CX, a modern software system that automates and simplifies critical and complex network tasks, delivers enhanced fault tolerance and facilitates zero-service disruption during planned or unplanned control-plane events.
The key innovations in ArubaOS-CX are its microservices style modular architecture, REST APIs, Python scripting capabilities and the Aruba Network Analytics Engine. The Aruba 8325 Switch Series provides line rate 1GbE, 10GbE, 25GbE, and 40GbE in a compact 1U form factor.
Features
Game-changing Business Agility
- The Aruba 8325 Switch Series is a campus core and aggregation switch and data center Top of Rack solution with an innovative and powerful approach to dealing with the cross-domain demands of the mobile, cloud, and IoT era.
- Fully programmable with ArubaOS-CX, it brings automation and visibility and helps troubleshoot via simple scripting.
- Aruba Network Analytics Engine provides the ability to monitor and troubleshoot the network, system, application and security related issues easily, through simple python agents and REST APIs.
- Offers high-speed fully distributed architecture with 6.4Tbps of switching capacity.
- Provides robust security and QoS with advanced Layer 2 and Layer 3 features including support for BGP, OSPF, VRF and VXLAN.
Modern Software System Simplifies and Automates
- The Aruba 8325 Switch Series is based on the new ArubaOS-CX, a modern software system that automates and simplifies many critical and complex network tasks.
- The built-in time series database enables customers and developers to develop software modules for historical troubleshooting, as well as analysis of historical trends, to predict and avoid future problems due to scale, security, and performance bottlenecks.
- It includes stability, independent monitoring and restart of individual software modules, and enhanced software process serviceability functions. It also allows individual software modules to be upgraded for higher availability.
High Performance and High Availability
- The Aruba 8325 Switch Series includes a high-speed, fully distributed architecture and provides up to 6.4Tbps switching capacity to meet the demands and bandwidth-intensive applications today and in the future.
- Aruba’s high-availability technology is Aruba VSX which has been designed from ground up to deliver continuous availability, virtualization and simplicity requirements. Redundant and hot-swappable power supplies and fans provide additional resiliency.
- The compact 1U switch delivers line rate 1GbE, 10GbE, 25GbE, 40GbE, and 100GbE with very low latency. Optimize for your deployment with models that provide 48 ports of 1/10/25 GbE + 8 ports of 40/100GbE or 32 ports of 40/100GbE.
New Aruba Data Center Networking Solution SKUs for HPE
- Hewlett Packard Enterprise and Aruba offer customers highly differentiated pre-engineered IT infrastructure solutions that span a wide variety HPE compute, storage, networking that span virtualization, vSAN, HCI, HPC, MCS, Microsoft, SAP HANA, Vmware, Nutanix application and IaaS service offerings.
- Aruba 10/25 and 40/100G CX switches can be deployed as part of these solutions and is often designed into these integrated solutions along with HPE ProLiant DL/DX servers, SimpliVity, Nimble, Synergy, Cray Shasta, Cray ClusterStor, Superdome Flex and HPE GreenLake.
- These ready-to-deploy, integrated IT data center solutions help simplify and speed IT service delivery while reducing the time, risk, and expertise needed to deploy complex solutions.
- Use these new tracking SKUs (R9FXXX) when Aruba CX switches are included in HPE integrated and mixed compute, storage and networking configuration and deployments.
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L3 |
| Quality of Service (QoS) | Ja |
| Warranty | |
| Base Warranty | Non Non |
| Poorten & interfaces | |
| Type basis-switching RJ-45 Ethernet-poorten | Nee |
| Vezel-optische connector | QSFP+, QSFP28 |
| Console port | RJ-45/micro-USB |
| Aantal QSFP28-poorten | 32 |
| Netwerk | |
| Netwerkstandaard | IEEE 802.1AX, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1t, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3by, IEEE 802.3x, IEEE 802.3z |
| 10G support | Ja |
| Port mirroring | Ja |
| Datastroombeheer | Ja |
| Verbindingsaggregatie | Ja |
| Spanning tree protocol | Ja |
| Ethernet LAN, data-overdrachtsnelheden | 40000,100000 Mbit/s |
| VLAN=ondersteuning | Ja |
| Data-uitwisseling | |
| Switchingcapaciteit | 6400 Gbit/s |
| Throughput | 1905 Mpps |
| MAC-adrestabel | 98304 entries |
| Jumbo Frames ondersteuning | Ja |
| Packet buffergeheugen | 32 MB |
| Beveiliging | |
| DHCP-functies | DHCP server |
| Access Control List (ACL) | Ja |
| IGMP snooping | Ja |
| SSH/SSL support | Ja |
| Authenticatie type | RADIUS, TACACS+ |
| Multicast-functies | |
| Multicast-ondersteuning | Ja |
| Protocollen | |
| Routing protocols | BGP, BGP4, OSPF, OSPFv2, OSPFv3, RIPng |
| IPv4- & IPv6-functies | IPv4/IPv6 access-control list (ACL) |
| Design | |
| Rack-montage | Ja |
| Vormfactor | 1U |
| Overtollige fans ondersteuning | Ja |
| Ventilatiesysteem | Luchtstroom achter-naar-voor |
| Luchtstroomrichting | Luchtstroom achter-naar-voor |
| Aantal ventilatoren | 6 ventilator(en) |
| Prestatie | |
| Type processor | Ja |
| Frequentie van processor | 2200 MHz |
| Type geheugen | SDRAM / Flash |
| Intern geheugen | 16384 MB |
| Flash memory | 8192 MB |
| Energie | |
| Stroombron | AC |
| Vermogenstoevoer inclusief | Ja |
| Redundante voeding | Ja |
| Aantal voedingen | 2 |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Vermogensverbruik (max) | 550 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Nee |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 95 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Hoogte, in bedrijf | 0 - 3048 m |
| Hoogte bij opslag | 0 - 4600 m |
| Gewicht en omvang | |
| Breedte | 438,4 mm |
| Diepte | 515,1 mm |
| Hoogte | 43,2 mm |
| Gewicht | 9,5 kg |
