Aruba 6200M 36G 12SR5 Class6 PoE 4SFP+ Switch, 36x ports 10/100/1000BASE-T Class, 6 PoE Ports,
ITCurry #: 1171AAW5 | Article #: R8Q71A-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The HPE Aruba Networking CX 6200 Switch Series is a next-generation family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks. With a cloud-centric design that combines a fully programmable operating system (OS) with the HPE Aruba Networking CX Network Analytics Engine, this switch family extends industry-leading deployment, monitoring, and troubleshooting to the access layer. Prepare your network for future demands with a powerful Gen7 ASIC that delivers an AI and Wi-Fi 7 ready, non-blocking performance. HPE Aruba Networking Virtual Stacking Framework (VSF) allows for stacking of up to 8 switches, providing scale and simplified management. This series includes fixed (CX 6200F) and modular (CX 6200M) switches with built-in high-speed uplinks and up to 1440W of PoE to support Internet of Things (IoT) devices such as security cameras and wireless APs.
What is new supporting point:
Enterprise-class connectivity with support for access control lists (ACLs), robust quality of service (QoS), and common protocols such as static and access OSPF routing
Up to 384 ports of scalability with 8-member HPE Aruba Networking Virtual Stacking Framework (VSF) stacking supported for both 24 and 48-port fixed and modular switches through the CX installer app
Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency
Real-time insights and actions through a built-in network analytics engine to securely maintain network performance, stability, and security
Dynamic segmentation enhanced with application-based policy to deliver secure access for users and Internet of Things (IoT)
HPE Aruba Networking Switch Multi-Edit Software supports for automation, configuration and verification
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L3 |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 36 |
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
| Aantal ge‹nstalleerde SFP modules | 4 |
| Console port | RJ-45/USB Type-C |
| Netwerk | |
| Netwerkstandaard | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| 10G support | Ja |
| Data-uitwisseling | |
| Switchingcapaciteit | 272 Gbit/s |
| Throughput | 130,9 Mpps |
| MAC-adrestabel | 32000 entries |
| Packet buffergeheugen | 8 MB |
| Design | |
| Rack-montage | Ja |
| Stapelbaar | Ja |
| Prestatie | |
| Physical stacking (units) | 8 |
| Type processor | Ja |
| Processormodel | ARM Cortex-A72 |
| Frequentie van processor | 1800 MHz |
| Type geheugen | DDR4-SDRAM |
| Intern geheugen | 8000 MB |
| Flash memory | 16000 MB |
| Energie | |
| Stroombron | AC |
| Vermogenstoevoer inclusief | Ja |
| AC-ingangsspanning | 200 - 240 V |
| Stroomverbruik (typisch) | 76 W |
| Energieverbruik opmerking | 76W at 230 VAC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Ja |
| Vermogen per poort Power over Ethernet (PoE) | 60 W |
| Totaal Power over Ethernet (PoE)-budget | 1440 W |
| Overige specificaties | |
| Latentie | 1 Gbps: 2.28 æSec 10 Gbps: 1.46 æSec |
| Geheugen en processor | CPU: Quad-core Arm Cortex-A72 at 1.8 GHz Memory: 8 GB DDR4 Flash: 16 GB eMMC |
| Aansluitingen | 36 x 10/100/1000BASE-T Class 6 PoE ports, supporting up to 60W per port 12 x HPE Smart Rate 1/2.5/5G BaseT Class 6 PoE ports supporting up to 60W per port 4 x 1/10G SFP ports (2 x LRM; 2 x LRM/MACSec 256) Supports PoE standards IEEE 802.3af, 802.3at, 802.3bt (up to 60W) 1 x USB-C console port 1 x USB Type-A host port 1 x OOBM 1 x RJ-45 console port |
| Prestatiebeheer | Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software |
| Gewicht (imperiaal) | 6,01 kg (13.2 lbs) |
| Afmetingen (B x D x H) (Brits) | 43,9 x 442,5 x 383,8 mm (1.73 x 17.4 x 15.1") |
| Fan | Fixed fans |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 45 øC |
| Gewicht en omvang | |
| Breedte | 43,9 mm |
| Diepte | 442,5 mm |
| Hoogte | 383,8 mm |
| Gewicht | 6,01 kg |
| Warranty | |
| Base Warranty | Non Non |
