Product Informatie
Removable front filter
- New front panel design with hinged removable mesh and tether-free bezel for easier access to front fan mounts
- Easy-to-clean filters on the front, top and base with full PSU coverage and convenient front access
- New front nylon filter that can be removed for increased airflow
Robust cooling
- Install up to 7 fans, front radiators up to 360 mm, or top radiators up to 240 mm
- Open interior layout creates a smooth airflow path from intake to exhaust
- Install up to 7x 120 mm or 4x 140 mm fans (1x 120 mm and 2x 140 mm Dynamic X2 fans included)
Fully featured
- Seamlessly integrated steel panel with steel frame support and bolt-free top-latching mechanism
- Flexible storage options supporting two 2.5”/3.5” drives and up to four SSDs (two SSD brackets included)
- Improved cable routing with three integrated cable alignment clips and six velcro straps
Top priority access
The fully removable top panel opens to provide excellent interior access
Spaciously compact
Clever layout enables the capacity of much larger cases
Type-C interface
USB 3.1 Gen 2 Type-C front I/O offers fast-charging and speeds up to 10 Gbps
Smooth and quiet operation
The sturdy steel drive trays are vibration-damped by cushioning rubber grommets
Full length shroud
A full-length power supply shroud readily conceals the drive cage and excess cabling
| Design | |
| Materiaal | Staal |
| Vormfactor | Tower |
| Soort | PC |
| Kleur van het product | Zwart |
| Supported motherboard form factors | ATX, micro ATX, Mini-ITX |
| Aantal 3.5" bays | 2 |
| Aantal 2.5" bays | 4 |
| Aantal uitbreidingssleuven | 7 |
| Zijraam | Nee |
| Geschikt voor | Gamen |
| Anti-stof filter | Ja |
| Verbeterd kabelbeheer | Ja |
| Reset button | Ja |
| Aan-/uitknop | Ja |
| Maximum CPU cooler hoogte | 16,9 cm |
| Maximum grafische kaart lengte | 36 cm |
| Maximum PSU lengte | 20 cm |
| Power voorraad | |
| Vermogenstoevoer inclusief | Nee |
| Ondersteunde vormfactoren stroomvoorziening | ATX |
| Poorten & interfaces | |
| Audio-ingangen | Ja |
| Audio-uitgang | Ja |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 2 |
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C | 1 |
| Koeling | |
| Aantal ge‹ntstalleerde ventilators voorkant | 2x 140 mm |
| Maximale aantal ventilators voorkant | 3 |
| Voorste ventilators ondersteunende diameters | 120,140 mm |
| Ge‹nstalleerde ventilators achterkant | 1x 120 mm |
| Maximaal aantal ventilators achterkant | 1 |
| Achterkant ventilators ondersteunende diameters | 120 mm |
| Maximaal aantal ventilators bovenkant | 2 |
| Bovenste ventilators ondersteunende diameters | 120,140 mm |
| Maximaal aantal ventilators onderkant | 1 |
| Ondersterste ventilators ondersteunende diameters | 120 mm |
| Ondersteunde afmetingen voorste radiatorventilator | 280,360 mm |
| Ondersteunde afmetingen achterste radiatorventilator | 120 mm |
| Ondersteunde ventilatorafmeting bovenste radiator | 240 mm |
| Opslagmedia | |
| Ondersteunde HDD-groottes | 2.5,3.5" |
| Gewicht en omvang | |
| Breedte | 210 mm |
| Diepte | 424 mm |
| Hoogte | 475 mm |
| Gewicht | 7,7 kg |
| Warranty | |
| Base Warranty | Non Non |
| Verpakking | |
| Breedte verpakking | 320 mm |
| Diepte verpakking | 542 mm |
| Hoogte verpakking | 554 mm |
| Gewicht verpakking | 9,3 kg |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 84733080 |
