Monitor LCD 17in 1739l Open Frame Intellitouch Plus
ITCurry #: M0133206 | Article #: E575274
Verwante producten
Product Informatie
Elo chassis LCD monitors have a long-lasting product cycle because the enclosure is controlled by Elo specifications. Future panel improvements are therefore possible without external changes. The 1739L features a wide viewing angle panel along with a unique, injection-molded minibezel and virtually invisible water-resistant seal. Available with a choice of touch technology including clear glass IntelliTouch surface wave for the utmost in optical quality.
- High quality panel with 160°x160° viewing angle
- 1000:1 contrast ratio, and 300-nit brightness (LCD panel)
- Long lasting product cycle-enclosure controlled by Elo specifications
- Future generation panels phased-in without external changes
- Integrated precision minibezel with water-resistant 0.5 mm seal
- Mounting options including rear-mount (two standard rear-mount brackets included) and VESA mount; optional front mount (see Accessories tab for details) and rack mount (see Accessories tab for details)
- AccuTouch Five-Wire Resistive, IntelliTouch Surface Wave, SecureTouch Surface Wave and CarrollTouch Infrared touch technology with dual serial/USB touch interface; Acoustic Pulse Recognition touch technology with USB touch interface. (SecureTouch monitors use a 3 mm chemically strengthened glass touch sensor.)
- Multilingual on-screen display (OSD)
- Worldwide agency approvals
- 3-D electronic design files available
| Beeldscherm | |
| Beeldschermdiagonaal | 43,2 cm (17") |
| Resolutie | 1280 x 1024 Pixels |
| Display technologie | LCD |
| Touchscreen | Ja |
| Touchscreen technologie | Rayleighgolf |
| Responstijd | 7,2 ms |
| Beeldscherm vorm | Flat |
| Ondersteunde grafische resoluties | 720 x 400, 832 x 624, 1280 x 960, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Beeldverhouding | 5:4 |
| Typische contrastverhouding | 1000:1 |
| Kijkhoek, horizontaal | 160ø |
| Kijkhoek, verticaal | 160ø |
| Beeldscherm, aantal kleuren | 16.78 miljoen kleuren |
| Helderheid | 225 cd/mý |
| Prestatie | |
| NVIDIA G-SYNC | Nee |
| AMD FreeSync | Nee |
| Design | |
| Kleur van het product | Zwart, Roestvrijstaal |
| Poorten & interfaces | |
| VGA (D-Sub)poort(en) | 1 |
| Ergonomie | |
| Paneelmontage-interface | 75 x 75,100 x 100 mm |
| Ophangsysteem voor aan de muur | Ja |
| On Screen Display (OSD) | Ja |
| Energie | |
| Soort voeding | DC |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -20 - 60 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 20 - 80 procent |
| Luchtvochtigheid bij opslag | 10 - 90 procent |
| Gewicht en omvang | |
| Breedte ( zonder voet ) | 368 mm |
| Diepte ( zonder voet ) | 49 mm |
| Hoogte (zonder voet ) | 306 mm |
| Gewicht (zonder voet) | 4 kg |
| Overige specificaties | |
| Effectieve beelddiameter | 338 x 270 mm |
| Mean time between failures (MTBF) | 50000 uur |
| Warranty | |
| Base Warranty | Non Non |
