LCD Monitor 1517l - 15in - Intellitouch Clear Black
ITCurry #: M0133215 | Article #: E829550-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The 1517L touchmonitor is built to withstand the rigors of continuous public use with a rugged "built for touch" design. Its stylish, thin and modern look is coupled with a retail-focused feature set and is an attractive solution for commercial touchmonitor needs. It is well suited for high use public venues where point-of-sale, point-of-information, point-of-service, shelf-level and countertop interactive digital signage and loyalty systems are found.
The 1517L is offered with AccuTouch five-wire resistive, IntelliTouch or iTouch zero-bezel surface acoustic wave technology. AccuTouch is widely used in retail and hospitality environments based on its proven ability to survive splashing liquids, food and grease. IntelliTouch and iTouch pure glass surface acoustic wave technology delivers the ultimate in optical quality for dry retail and hospitality applications.
The optional 3-track magnetic stripe reader (MSR), programmable to either HID or Keyboard Emulation, is easily installed by the user, providing an elegant, integrated solution and eliminating the need for external brackets or attachments.
The 1517L touchmonitor is environmentally friendly, lightweight and uses less power with state-of-the-art LED backlights in the display panel.
- Sleek and thin design with “built for touch” reliability.
- Flexible and space-saving.
- 60% Energy savings using LED technology .
- Zero-bezel touchscreen versions for a smooth, easy-to-clean surface.
- Antiglare or Clear glass.
- Removable base and mounting options including VESA, wall and pole-mounting for installation flexibility and capped through-mount holes on base for table-top security.
- 15” diagonal active matrix TFT LED-backlit LCD.
- Active Display Area: 11.97 x 8.98 inches/304 x 228 mm.
- 4:3 aspect ratio.
- 1024 x 768 native resolution. Other resolutions supported.
- USB and RS232 serial connections.
- Touch technology: AccuTouch (single- touch), IntelliTouch (single-touch) and iTouch (single-touch).
- Typical power consumption: 12W, internal and external power options.
| Beeldscherm | |
| Beeldschermdiagonaal | 38,1 cm (15") |
| Resolutie | 1024 x 768 Pixels |
| Oorspronkelijke beeldverhouding | 4:3 |
| Display technologie | LCD |
| Touchscreen | Ja |
| Touch screen type | Tafelblad |
| Responstijd | 16 ms |
| Beeldscherm vorm | Flat |
| Ondersteunde grafische resoluties | 720 x 400, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Beeldverhouding | 4:3 |
| Typische contrastverhouding | 700:1 |
| Kijkhoek, horizontaal | 160ø |
| Kijkhoek, verticaal | 140ø |
| Beeldscherm, aantal kleuren | 16.78 miljoen kleuren |
| Frequentiebereik horizontaal | 31,5 - 60 kHz |
| Frequentiebereik verticaal | 56 - 75 Hz |
| Helderheid | 225 cd/mý |
| LED backlight | Ja |
| Prestatie | |
| NVIDIA G-SYNC | Nee |
| AMD FreeSync | Nee |
| Design | |
| Kleur van het product | Zwart |
| Glas dikheid | 4,3 cm |
| Poorten & interfaces | |
| Aantal upstream-poorten | 1 |
| VGA (D-Sub)poort(en) | 1 |
| RS-232 port | 1 |
| Warranty | |
| Base Warranty | Non Non |
| Ergonomie | |
| Paneelmontage-interface | 75 x 75 mm |
| On Screen Display (OSD)-talen | Vereenvoudigd Chinees, Traditioneel Chinees, Duits, Engels, Spaans, Frans, Italiaans, Japans |
| Aantal On Screen Display-talen | 8 |
| Energie | |
| Stroomverbruik (typisch) | 12 W |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Soort voeding | AC/DC |
| Voltage tolerantie | 5 procent |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -20 - 60 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 20 - 80 procent |
| Luchtvochtigheid bij opslag | 10 - 90 procent |
| Gewicht en omvang | |
| Breedte apparaat (met standaard) | 358 mm |
| Diepte apparaat (met standaard) | 197 mm |
| Hoogte apparaat (met standaard) | 319 mm |
| Gewicht (met standaard) | 4,3 kg |
| Verpakking | |
| Breedte verpakking | 487 mm |
| Diepte verpakking | 231 mm |
| Hoogte verpakking | 485 mm |
| Gewicht verpakking | 7,3 kg |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85285210 |
| Overige specificaties | |
| Afmetingen (B x D x H) met voet | 358 x 197 x 319 mm |
| Effectieve beelddiameter | 228 x 304 mm |
| Mean time between failures (MTBF) | 50000 uur |
