TRIPP LITE Swivel/Tilt Wall Mount for 37" to 70" TVs and Monitors
ITCurry #: 57904804 | Article #: DWM3770X-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The VESA-compliant DWM3770X Swivel/Tilt Wall Mount allows you to mount your flat-panel television, monitor or other display on the wall. Ideal for home theaters, classrooms, boardrooms, hotels, bars and restaurants, it fits most flat-panel displays from 37 to 70 inches.
The articulating arm has six pivots that adjust independently for angle to give you maximum flexibility in positioning your display to fit your environment and comfort level. A 120° swivel, -15° to +15° tilt and -3° to +3° screen level adjustment capability minimizes glare and provides comfortable viewing from multiple angles.
Durable all-metal frame with scratch-resistant powder-coated finish supports up to 165 lbs (74.8 kgs). Mounting hardware included. Built-in bubble level allows accurate display leveling. Conforms to VESA-compliant displays with any of the following mounting hole patterns: 100 x 100 mm, 100 x 200 mm, 200 x 100 mm, 200 x 200 mm, 200 x 300 mm, 200 x 400 mm, 300 x 200 mm, 300 x 300 mm, 300 x 400 mm, 400 x 200 mm, 400 x 300 mm, 400 x 400 mm, 500 x 200 mm, 500 x 300 mm, 500 x 400 mm, 600 x 300 mm and 600 x 400 mm
| Montage | |
| Minimale schermgrootte | 94 cm (37") |
| Maximale gewichtscapaciteit | 75 kg |
| Maximale schermgrootte | 177,8 cm (70") |
| Montage interface compatibiliteit (min) | 100 x 100 mm |
| Montage interface compatibiliteit (max) | 600 x 400 mm |
| Paneelmontage-interface | 100 x 100,100 x 200,200 x 100,200 x 200,200 x 300,200 x 400,300 x 200,300 x 400,300 x 300,400 x 200,400 x 400,400 x 300,500 x 200,500 x 300,500 x 400,600 x 300,600 x 400 |
| Aantal displays ondersteund | 1 |
| Montagewijze | Muur |
| Ergonomie | |
| In hoogte verstelbaar | Ja |
| Bereik kantelhoek | -15 - 15ø |
| Draaihoek | 120ø |
| Horizontaal draaibaar | -3 - 3ø |
| Design | |
| Kleur van het product | Zwart |
| Warranty | |
| Base Warranty | Non Non |
| Technische details | |
| Land van herkomst | China |
| Inhoud van de verpakking | |
| Gebruikershandleiding | Ja |
| Montage gereedschap | Ja |
| Gewicht en omvang | |
| Breedte | 601 mm |
| Diepte | 524 mm |
| Hoogte | 440 mm |
| Gewicht | 7,88 kg |
| Verpakking | |
| Breedte verpakking | 241,3 mm |
| Diepte verpakking | 708,7 mm |
| Hoogte verpakking | 111,8 mm |
| Gewicht verpakking | 9,34 kg |
| Logistieke gegevens | |
| (Buitenste) hoofdverpakking breedte | 251,5 mm |
| (Buitenste) hoofdverpakking lengte | 718,8 mm |
| (Buitenste) hoofdverpakking hoogte | 254 mm |
| (Buitenste) hoofdverpakking brutogewicht | 19,1 kg |
| Hoeveelheid per (buitenste) hoofdverpakking | 2 stuk(s) |
| GTIN (EAN/UPC)-nummer (buitenste) hoofdverpakking | 10037332187434 |
| Code geharmoniseerd systeem (HS) | 85299097 |
