Product Informatie
DIGITUS® wall-mounted enclosures are manufactured, designed and developed to meet the high demands of IT infrastructure.
- Compact housing for installations where space is limited
- Ready for immediate use: Delivery is assembled
- Flexible cable routing options thanks to protected openings in the roof and floor
- Lockable safety glass door with 200° door opening angle
- Depth-adjustable 254 mm (10") profile rails
- Load capacity for the installation of components: 30 kg
Whether in the home, office or in sub-distribution boards where space is limited: With the compact 254 mm (10") solutions, you can install your network wherever you want. Available in three height units (6U, 9U, 12U), the wall-mounted enclosures are equipped with a full glass door and a cable entry with brushes in the top and bottom. A pair of galvanized 254 mm (10") profile rails labelled with legible height units are installed inside. These can be adjusted in depth. Each cabinet is a robust steel construction made of up to 1.5 mm thick sheet steel. The coloring takes the form of electrostatic powder coating in the standard colors grey (RAL 7035) and black (RAL 9005). Door hinges can be changed. Furthermore, the cabinets can be completely dismantled if required thanks to the demountable design.
| Kenmerken | |
| Rackcapaciteit | 6U |
| Soort | Wandrek |
| Maximale gewichtscapaciteit | 30 kg |
| Kleur van het product | Grijs |
| Materiaal | Staal |
| Voordeurconstructie | Glas |
| Inbegrepen zijpanelen | Ja |
| Internationale veiligheidscode (IP) | IP20 |
| Gewicht en omvang | |
| Maat | 25,4 cm (10") |
| Breedte | 312 mm |
| Diepte | 300 mm |
| Hoogte | 310 mm |
| Breedte | 32 cm (12.6") |
| Diepte (imperiaal) | 34 cm (13.4") |
| Hoogte | 31 cm (12.2") |
| Verpakking | |
| Breedte verpakking | 350 mm |
| Diepte verpakking | 360 mm |
| Verpakkingsvolume | 50400 cmü |
| Gewicht verpakking | 8 kg |
| Logistieke gegevens | |
| Code UK-handelstarief | 94032080 |
| Land van herkomst | China |
| Code geharmoniseerd systeem (HS) | 85381000 |
| Overige specificaties | |
| Afmetingen (B x D x H) | 320 x 340 x 310 mm |
| Warranty | |
| Base Warranty | Non Non |
