SNMP card V2.0,for DIGITUS OnLine UPS rack mounts DN-170xxx
ITCurry #: M9239282 | Article #: DN-170100-1-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The SNMP card offered in a plug and play design for easy integration allows remote access for monitoring the UPS operations.
- Plug-and-play Installation
- Scheduling Shutdown/ Start-up/ Reboot of the UPS remotely
- Secure Authentication
- Automatic sending of individual mails by integrated e-mail client
- User-friendly Web Interface
The Digitus SNMP card is an optional add-on solution for control and monitoring of connected Online UPS units. With internet, users can access the UPS from anywhere when integrated with the SNMP card. The solution allows to perform certain critical tasks such as scheduled shutdowns and startups. The auto-shutdown software helps to protect the servers and workstations from data loss due to power failure. Logging of measured values and alarm events makes it possible to track the operational history of the UPS. It is suitable for all DIGITUS® OnLine UPS units of DN-170xxx series.
| Kenmerken | |
| Type product | Netwerkbeheerkaart |
| Kleur van het product | Zwart |
| LED-indicatoren | Activiteit, Link, Stroom, Status |
| Poorten & interfaces | |
| Soort aansluiting | RS-232 |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| Netwerk | |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN, data-overdrachtsnelheden | 100 Mbit/s |
| Bekabelingstechnologie | 10/100 |
| Ondersteunde beveiligingsalgoritmen | SNMP |
| Beheerfuncties | |
| Web-gebaseerd management | Ja |
| Ondersteunde netwerkprotocollen | TCP/IP, UDP, SNMP, SSL, Telnet, HTTP, SMTP, DHCP, DNS, etc. |
| Wachtwoordbeveiliging | Ja |
| Syslog | Ja |
| Energie | |
| Ingangsspanning | 8 - 15 V |
| Gewicht en omvang | |
| Breedte | 52 mm |
| Diepte | 81 mm |
| Hoogte | 26 mm |
| Breedte verpakking | 89 mm |
| Diepte verpakking | 51 mm |
| Hoogte verpakking | 202 mm |
| Gewicht verpakking | 132,5 g |
| Inhoud van de verpakking | |
| Snelstartgids | Ja |
| Technische details | |
| Processorfamilie | ARM |
| Frequentie van processor | 300 MHz |
| Flash memory | 128 MB |
| RAM-capaciteit | 64 MB |
| RAM-type | SDRAM |
| Verpakkingsvolume | 916,878 cmü |
| Logistieke gegevens | |
| Code UK-handelstarief | 85176200 |
| Land van herkomst | China |
| Aantal per verpakking | 1 stuk(s) |
| Warranty | |
| Base Warranty | Non Non |
