Long Range PoE Extender 10/100 Mbit ideal for harsh outdoor environment

ITCurry #: M9239154 | Article #: DN-95129
Prijs:
31,14 Excl. btw
Levering in Benelux:
GRATIS Levering bij bestelling van meer dan € 100 zbtw.
Nu niet op voorraad. Bel ons!

Verwante producten

slide 7 to 11 of 14

Product Informatie

The PoE Extender DN-95129 is a versatile and durable device that complies with IEEE802.3af/at/bt standards. It can transmit both data and power on a single network cable and supports 10/100Mbps data transmission. With a rugged plastic housing and IP67 protection class, this device is ideal for outdoor environments. It can transmit power over the internet (PoE) up to 100 meters with 100Mbps, and up to 300 meters with 100Mbps or 800 meters with 10Mbps using two PoE extender units. The DN-95129 is easy to install and use, and no configuration is required. With an operating temperature range of -10°C to 55°C, this device is suitable for use in a variety of environments.

- Complies with IEEE802.3af/at/bt Standard
- Capable of transmitting both data and power on a single network cable
- Support 10/100Mbps data transmission
- Single DN-95129 use with a regular PoE Switch, power over internet(PoE) distance is 100 meters maximum with 100Mpbs
- Two DN-95129 use with a regular PoE Switch, power over internet(PoE) distance is 300 meters with 100Mbps or up to 800 meters maximum with 10Mbps
- 1 PD receiving terminal ,1 PSE supply terminal
- Plug-and-play, no configuration required
- Standard: IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3af, IEEE802.3at, IEEE802.3bt
- Port: 2*10/100Mbps RJ45 ports
- It's ideal for harsh outdoor environment

Introducing the PoE Extender DN-95129 - the perfect solution for extending your network's reach without compromising on performance. This compact and versatile device is designed to comply with IEEE802.3af/at/bt standards, ensuring seamless integration with your existing network infrastructure. With its rugged plastic housing and IP67 protection class, the DN-95129 is built to withstand even the harshest outdoor environments. Capable of transmitting both data and power on a single network cable, this PoE extender supports 10/100Mbps data transmission, ensuring fast and reliable connectivity. Using a single DN-95129 with a regular PoE switch, the Extender can transmit power over the internet (PoE) up to a maximum distance of 100 meters with 100Mbps. And with two PoE extender units, the PoE distance can be extended to 300 meters with 100Mbps or up to 800 meters maximum with 10Mbps. The DN-95129 features one PD receiving terminal and one PSE supply terminal, making it easy to install and use. Simply plug and play - no configuration is required. And with an operating temperature range of -10°C to 55°C, this device is perfect for use in a wide range of environments. In summary, the PoE Extender DN-95129 is a reliable and cost-effective solution for extending your network's reach. Its compliance with industry standards, rugged design, and ease of use make it an ideal choice for any outdoor network setup.

Prestatie
Soort Netwerkzender
Maximaal bereik 800 m
Overdrachtssnelheid 100 Mbit/s
Ethernet LAN, data-overdrachtsnelheden 10,100 Mbit/s
Internationale veiligheidscode (IP) IP67
Plug and play Ja
Netwerk
Bekabelingstechnologie 10/100Base-T(X)
Netwerkstandaard IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Poorten & interfaces
Aantal Ethernet LAN (RJ-45)-poorten 2
RJ-45 invoer ports 1
RJ-45 uitgang ports 1
Design
Kleur van het product Wit
Materiaal behuizing Kunststof
Aantal per verpakking 1 stuk(s)
Land van herkomst China
Energie
Power over Ethernet (PoE) Ja
Eisen aan de omgeving
Bedrijfstemperatuur (T-T) -10 - 55 øC
Temperatuur bij opslag -40 - 70 øC
Relatieve vochtigheid in bedrijf (V-V) 10 - 90 procent
Luchtvochtigheid bij opslag 5 - 90 procent
Gewicht en omvang
Breedte 29 mm
Diepte 156,5 mm
Hoogte 29 mm
Inhoud van de verpakking
Snelstartgids Ja
Verpakking
Breedte verpakking 32 mm
Diepte verpakking 175 mm
Hoogte verpakking 32 mm
Verpakkingsvolume 179,2 cmü
Gewicht verpakking 104,87 g
Logistieke gegevens
Code UK-handelstarief 85176200
Warranty
Base Warranty Non Non
