LC/APC Fiber Optic Fast connector 10 Pk
ITCurry #: M9239252 | Article #: DN-FC-9101-APC-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Fast connectors are designed to enable quick and easy termination of fibers in the field. For uncomplicated fast repair of existing installations as well as for new installations, e.g. for Fttx in-house cabling.
- Quick and easy to install
- Low attenuation values
- Applicable for all common singlemode fibers
- For fiber cladding with 0.9mm thickness
- LC/APC ceramic ferrule with 2.50mm thickness
- Robust strain relief
- Durable index matching gel
- No complex splicing equipment necessary
- Low tooling requirements
- Low tool effort
The LC/APC fast connectors are used to close optical cables and fast cross-connection, cable repair, various switching nodes in FTTH networks to form a continuous optical patch. They completely eliminate the need for hand polishing in the field. The mechanical splice technology ensures precise fiber alignment and offers an immediate low loss termination for single-mode optical fibers. The attenuation obtained does not exceed 0.3 dB. The connectors can be used in all optical networks where UPC type connector is required. It is suitable for optical cabling in primary/secondary/tertiary cabling and for use in FTTx networks.
| Kenmerken | |
| Aansluiting type | LC/APC |
| Geslacht connector | Mannelijk |
| Kleur van het product | Grijs |
| Draad modus structuur | Single-mode |
| Verpakking | |
| Aantal per verpakking | 10 stuk(s) |
| Breedte verpakking | 100 mm |
| Diepte verpakking | 240 mm |
| Hoogte verpakking | 150 mm |
| Gewicht verpakking | 40 g |
| Warranty | |
| Base Warranty | Non Non |
