HDMI Extender 4K Set over IP over network cable (CAT 5/5e/6/7), 4K2K/30Hz, black
ITCurry #: M9237741 | Article #: DS-55122-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Use additional receiver units (DS-55123) and your existing network infrastructure to display your video content on up to 253 screens (IP connection)
- Use additional receiver units (DS-55123) and your existing network infrastructure to display your video content on up to 253 screens (IP connection)
- Extends 4K video content to up to 120 m with a CAT 6 cable (point-to-point connection)
- Signal extension (unlimited distance) via the existing local network infrastructure (IP connection)
- Supports 4K (30Hz), 3840x2160p resolution
- Supports CAT 5, CAT 5e, CAT 6 and CAT 7 network cables
- HDMI bandwidth: 10.2 Gbit/s (max.)
- Supports HDCP 1.4
The 4K HDMI via IP Extender Set (DS-55122) is a high-performance video distribution system consisting of a transceiver unit. It extends 4K HDMI signals to up to 120 m via a CAT6 network cable (point-to-point connection). In addition, you can use a network switch and the individual receiver units (DS-55123) to distribute your video content to up to 253 displays via the already existing network (IP connection). The additional integrated unidirectional IR interface allows a remote control of the input source.
| Kenmerken | |
| Soort | AV-zender & ontvanger |
| Maximum resolutie | 3840 x 2160 Pixels |
| Ondersteundende kabel types | Cat5, Cat5e, Cat6 |
| Maximaal bereik | 120 m |
| Ondersteunde video-modi | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
| Bandbreedte | 10,2 Gbit/s |
| HDCP | Ja |
| Materiaal | Metaal |
| Kleurdiepte | 24 Bit |
| 3D | Ja |
| Kleur van het product | Zwart |
| Poorten & interfaces | |
| Connectiviteitstechnologie | Bedraad |
| RJ-45 invoer ports | 1 |
| RJ-45 uitgang ports | 1 |
| HDMI in | 1 |
| Aantal HDMI-uitgangen | 1 |
| HDMI versie | 1.4 |
| Remote (IR) ingang | 1 |
| Remote (IR) uitgang | 1 |
| Aansluiting voor netstroomadapter | Ja |
| Energie | |
| Bedrijfsspanning (zender) | 5 V |
| Output current | 2 A |
| Bedrijfsspanning (ontvanger) | 5 V |
| Stroomverbruik (typisch) | 4 W |
| Power over Ethernet (PoE) | Nee |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 60 øC |
| Gewicht en omvang | |
| Breedte | 107,3 mm |
| Diepte | 94 mm |
| Hoogte | 23,7 mm |
| Gewicht | 167 g |
| Verpakking | |
| Breedte verpakking | 199 mm |
| Diepte verpakking | 149 mm |
| Hoogte verpakking | 80 mm |
| Gewicht verpakking | 845 g |
| Inhoud van de verpakking | |
| Inclusief AC-adapter | Ja |
| Gebruikershandleiding | Ja |
| Inclusief IR-versterker | Ja |
| Inclusief IR-ontvanger | Ja |
| Technische details | |
| Land van herkomst | China |
| Verpakkingsvolume | 2372,08 cmü |
| Logistieke gegevens | |
| Code UK-handelstarief | 85176200 |
| Warranty | |
| Base Warranty | Non Non |
