USB Gen1 Type-c, 6-in-1 Hub With Hdmi 8k30hz, 2xUSB
ITCurry #: M4192933 | Article #: CSV-1596-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The Club 3D CSV-1596 is a USB Gen1 Type-C, 6-in-1 Hub with HDMI™8K30Hz-4K120Hz, 2xUSB Type-A, RJ45 and 2xUSB Type-C, Data and PD charging 100 watt, providing an ideal solution for extending the port of Type-C/Thunderbolt host (PC/Laptop/Mobile phone,etc.), especially for those host with a single Type-C port. This hub adopts the latest DP1.4 Alt mode supported IC, enabling to output HDMI™ video with max. 8K30Hz-4K120Hz and at the meanwhile transfer USB 3.1 data with max 5Gbps. The USB Type-A and Type-C data ports allow you to connect 4 USB devices simultaneously. 1 Gigabit Ethernet for super fast Ethernet. Besides, the Type-C female supports PD 3.0 PD Charging 100W (15W is dedicated to the functioning of this product, the rest power(max 85W) will be passed to charge for the host. This 6-in-1 Hub will work on all DP Alt mode supported Type-C hosts.
| Poorten & interfaces | |
| Hostinterface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 2 |
| Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C | 2 |
| USB Power Delivery (USB PD) | Ja |
| USB Power Delivery herziening | 3.0 |
| USB Power Delivery tot max. | 100 W |
| Aantal HDMI-poorten | 1 |
| HDCP | Ja |
| HDCP versie | 1.4/2.3 |
| USB Type-C DisplayPort alternatieve modus | Ja |
| Netwerk | |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| Ethernet LAN, data-overdrachtsnelheden | 100,1000 Mbit/s |
| Prestatie | |
| HD type | 8K Ultra HD |
| Aantal displays ondersteund | 1 |
| Maximale refresh snelheid | 120 Hz |
| Kleur van het product | Zwart |
| HDR-ondersteuning | Ja |
| Hub-interfaces | HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Plug and play | Ja |
| Certificering | ROHS, FCC, CE EMI |
| Energie | |
| Spanning | 5 V |
| Output current | 1,5 A |
| Vermogensverbruik (max) | 7,5 W |
| Software | |
| Ondersteunt Windows | Ja |
| Ondersteunt Mac-besturingssysteem | Ja |
| Gewicht en omvang | |
| Breedte | 126 mm |
| Diepte | 32 mm |
| Hoogte | 35 mm |
| Gewicht | 89 g |
| Verpakking | |
| Aantal per verpakking | 1 stuk(s) |
| Breedte verpakking | 70 mm |
| Diepte verpakking | 35 mm |
| Hoogte verpakking | 320 mm |
| Gewicht verpakking | 136 g |
| Packaging composition | |
| Gewicht van plastic verpakking | 5 g |
| Gewicht papier-/kartonverpakking | 42 g |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 8473 3020 |
| Overige specificaties | |
| Snoerlengte | 0,3 m |
| Soort kabel | Round cable |
| Warranty | |
| Base Warranty | Non Non |
