Product Informatie
Designed for operational simplicity to lower TCO, this platform also offers superior security capabilities. The switches deliver best-in-class energy efficiency, while preserving your investments through mixed stacking with existing Catalyst 2960-S and SF switches.
Beheerfuncties | |
Switch type | Managed |
Switch-laag | L2/L3 |
Quality of Service (QoS) | Ja |
Web-gebaseerd management | Ja |
ARP-inspectie | Ja |
MIB-ondersteuning | Y |
Poorten & interfaces | |
Aantal basis-switching RJ-45 Ethernet-poorten | 24 |
Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
Aantal Gigabit Ethernet (koper)-poorten | 24 |
Aantal moduleslots SPF | 4 |
Console port | RJ-45 |
Aantal USB 2.0-poorten | 2 |
Netwerk | |
Netwerkstandaard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Full duplex | Ja |
Verbindingsaggregatie | Ja |
Broadcast stormbeheer | Ja |
Rate limiting | Ja |
Auto MDI/MDI-X | Ja |
Spanning tree protocol | Ja |
Auto-negotiation | Ja |
VLAN=ondersteuning | Ja |
Virtuele LAN-functies | Private VLAN |
Aantal VLANs | 1023 |
Data-uitwisseling | |
Switchingcapaciteit | 216 Gbit/s |
Throughput | 71,4 Mpps |
MAC-adrestabel | 16000 entries |
Aantal wachtrijen | 8 |
Aantal statische routes | 1000 |
Jumbo Frames ondersteuning | Ja |
Jumbo frames | 9216 |
Beveiliging | |
DHCP-functies | DHCP server |
Access Control List (ACL) | Ja |
Regels voor toegangscontrolelijst (ACL) | 3 |
IGMP snooping | Ja |
Ondersteunde beveiligingsalgoritmen | 802.1x RADIUS, SNMP, SSH |
SSH/SSL support | Ja |
Authenticatie | MAC-gebaseerde authenticatie, Poortgebaseerde authenticatie |
Multicast-functies | |
Multicast-ondersteuning | Ja |
Aantal gefilterde multicast-groepen | 1000 |
Protocollen | |
Beheerprotocollen | SNMPv3 |
Wissel protocols | UDP, TCP, RADIUS/TACACS+ |
Design | |
Rack-montage | Ja |
Stapelbaar | Ja |
Vormfactor | 1U |
Kleur van het product | Zwart |
LED-indicatoren | Ja |
Veiligheid | UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1 |
Prestatie | |
Physical stacking (units) | 8 |
Type processor | Ja |
Frequentie van processor | 600 MHz |
Type geheugen | DRAM |
Intern geheugen | 512 MB |
Flash memory | 128 MB |
Geluidsniveau | 43 dB |
Mean time between failures (MTBF) | 324280 uur |
Energie | |
Vermogenstoevoer inclusief | Ja |
Redundante voeding | Ja |
Aantal voedingen | 1 |
AC-ingangsspanning | 100 - 240 V |
AC-ingangsfrequentie | 50 - 60 Hz |
Stroom | 5 A |
Stroomverbruik (typisch) | 49 W |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) | Ja |
Hoeveelheid Power over Ethernet (PoE) ports | 24 |
Aantal Power over Ethernet plus (PoE +)-poorten | 12 |
Totaal Power over Ethernet (PoE)-budget | 370 W |
Eisen aan de omgeving | |
Bedrijfstemperatuur (T-T) | -5 - 40 øC |
Temperatuur bij opslag | -25 - 70 øC |
Relatieve vochtigheid in bedrijf (V-V) | 10 - 95 procent |
Luchtvochtigheid bij opslag | 10 - 95 procent |
Hoogte, in bedrijf | 0 - 3000 m |
Hoogte bij opslag | 0 - 4000 m |
Gewicht en omvang | |
Breedte | 445 mm |
Diepte | 368 mm |
Hoogte | 45 mm |
Gewicht | 5,8 kg |
Inhoud van de verpakking | |
Meegeleverde kabels | AC |
Gebruiksaanwijzing | Ja |
Certificaten | |
Certificering | 47CFR Part 15 (CFR 47) AS/NZS CISPR22 CISPR22 EN55022 ICES003 VCCI EN61000-3-2 EN61000-3-3 KN22 CNS13438 |
Warranty | |
Base Warranty | Non Non |
