Q1809-le 150mm Bullet Camera

ITCurry #: 13836587 | Article #: 03019-001
Prijs:
4137,07 Excl. btw
Levering in Benelux:
GRATIS Levering.
Nu niet op voorraad. Bel ons!

Verwante producten

Product Informatie

Ideal for long distance surveillance, this all-in-one, outdoor-ready bullet camera delivers superior image quality in 41 MP with high light sensitivity and extremely high pixel density.

See all the details
Built on a dual Axis system-on-chip, this device delivers extreme detail over great distances and excellent forensic value. It offers 41 MP at 15 fps or 8K at up to 30 fps. And a 4/3” image sensor ensures exceptional low-light performance. With a custom-made, tele Canon lens, it’s perfect for long-distance surveillance and delivers extremely high pixel density. Electronic image stabilization (EIS) ensures smooth video in situations where a camera is subject to vibrations, for instance, at sports arenas or windy harbors. Furthermore, Axis Zipstream reduces bandwidth and storage requirements without compromising image quality.

All-in-one and ready for everything
This powerful camera offers everything you need and is out-of-the-box ready to use. Enclosed in a robust aluminum casing, it also includes a mounting arm for easy installation. And a spacious back box ensures secure cable management. It features a custom-made, tele (50 – 150 mm) Canon lens and 21°-7° horizontal field of view. With 3x zoom, it’s ideal for identification purposes. In addition, thanks to PoE out, you can connect and power another device without any additional cabling. This eliminates the need to rent extra ports and simplifies installation.

Secure and robust surveillance
AXIS Q1809-LE includes Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. This robust, weather-protected, outdoor-ready camera is IP66-, IP67-, IK10- and NEMA 4X-rated and features a IK08-rated impact-resistant glass front window. It has an operating temperature range from -40 °C to 55 °C (-40 °F to 131 °F). Furthermore, surge protection minimizes damage in the case of a power surge.

Prestatie
Soort IP-beveiligingscamera
Ondersteuning voor plaatsing Buiten
Connectiviteitstechnologie Bedraad
PTZ control Ja
PTZ-modi Digitale PTZ
Wide Dynamic Range (WDR) Ja
Dag/nacht modus Ja
Infrarood (IR)-afsluitingsfilter Ja
Certificering CSA, UL/cUL, CE, EAC, VCCI, RCM
Design
Vormfactor Kogel (vorm)
Montagewijze Plafond/muur
Kleur van het product Zwart, Wit
Materiaal behuizing Aluminium, Glas
Veiligheidsfunties Schokbestendig
Internationale veiligheidscode (IP) IP66, IP67
IK code IK10
Camera
Minimale belichting 0,04 Lux
Draaihoek 270ø
Kijkhoek lens, horizontaal 21 - 7ø
Kijkhoek lens, verticaal 12 - 4ø
Bereik kantelhoek 0 - 90ø
Pan bereik -180 - 180ø
Pixelgrootte camera 2,315 æm
Camera sluitertijd 1/15500 - 2 s
Beeldsensor
Aantal sensoren 1
Omvang optische sensor 101,6 / 3 mm (4 / 3")
Type beeldsensor CMOS
Lenssysteem
Zoomcapaciteit Ja
Aantal lenzen 1
Brandpuntbereik 50 - 150 mm
Focus Gemotoriseerd
Maximum aperture number 4
Detectieafstand (groothoek) 853,8 m
Detectieafstand (tele) 2551,6 m
Observatieafstand (groothoek) 338,8 m
Observatieafstand (tele) 1012,6 m
Herkenningsafstand (groothoek) 170,8 m
Herkenningsafstand (tele) 510,2 m
Identificatieafstand (groothoek) 85,4 m
Identificatieafstand (tele) 255,2 m
Dichtstbijzijnde focus afstand 5 m
Nachtkijker
Nachtvisie Ja
LED-type IR
Infrarood wavelength 900 nm
Video
Maximum resolutie 7680 x 4320 Pixels
Totaal aantal megapixels 41 MP
Ondersteunde videoformaten AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
Videocompressieformaten H.264, H.265
Ondersteunde grafische resoluties 160 x 120, 160 x 90, 1280 x 800, 3840 x 2160
Maximaal 30 frames per seconde 30 fps
Videostreaming Ja
Ruisonderdrukking Ja
Ruisonderdrukkingstechnologie 2D-ruisonderdrukking, 3D-ruisonderdrukking
Type sterkteregeling Auto
Aanpassing van de afbeeldingskwaliteit Helderheid, Contrast, Spiegel, Scherpte
Tekstoverlay Ja
Beeldstabilisator Ja
Bitratecontrole Variabele bitsnelheid (VBR)
Audio
Ondersteund audioformaat AAC-LC, ADPCM, G.711, G.726, LPCM, PCM
Sample rate 48 kHz
Signaal/ruis-verhouding 55 dB
Netwerk
Ethernet LAN Ja
Netwerkstandaard IEEE 802.1AE, IEEE 802.1x
Ondersteunde netwerkprotocollen IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSd , HTTP/2, TLSd , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP© , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Wifi Nee
Bluetooth Nee
Quality of Service (QoS) Ja
Methode voor streaming Multicast
Opslagmedia
Ingebouwde HDD Nee
Ge‹ntegreerde geheugenkaartlezer Ja
Compatibele geheugenkaarten MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory 8192 MB
ROM-capaciteit 4096 MB
Poorten & interfaces
Microfoon, line-in ingang Ja
Klemmenblokpoort Ja
Aansluiting voor netstroomadapter Ja
Beveiliging
Wachtwoordbeveiliging Ja
Ondersteunde beveiligingsalgoritmen EAP-TLS, HTTPS
Type waarschuwingsnotificatie E-mail
Pixelteller Ja
Samenvattingsverificatie Ja
Beheerfuncties
Cloud-beheerd Ja
Op afstand bedienbaar Ja
Energie
Type stroombron DC, Power over Ethernet (PoE)
Stroomverbruik (typisch) 17,6 W
Vermogensverbruik (max) 35 W
Stroomverbruik (voeding via Ethernet (PoE)) 18,9 W
Eisen aan de omgeving
Bedrijfstemperatuur (T-T) -40 - 55 øC
Temperatuur bij opslag -40 - 65 øC
Relatieve vochtigheid in bedrijf (V-V) 10 - 100 procent
Luchtvochtigheid bij opslag 5 - 95 procent
Gewicht en omvang
Diepte 411 mm
Hoogte 183 mm
Diameter 18,3 cm
Gewicht 3,2 kg
Duurzaamheid
Certificaten van naleving REACH, RoHS
Inhoud van de verpakking
Aantal cameras 1
Warranty
Base Warranty Non Non
