2-port USB True 4k DisplayPort KVM Switch With USB 3.0

ITCurry #: 90314308 | Article #: CS1922ATC-AT-G
Prijs:
689,30 Excl. btw
Levering in Benelux:
GRATIS Levering.
Nu niet op voorraad. Bel ons!

Verwante producten

slide 6 to 10 of 15

Product Informatie

The ATEN CS1922ATC 2 Port USB 3.0 4K DisplayPort KVMP™ Switch for ATC is tailor-made for Air Traffic Control scenarios. It supports 2Kx2K resolution, making it perfect for radar monitoring, and also enables constant monitoring of flight information and mission-critical processes.

The Zero-Second Switch function ensures nearly real-time switching without any black screens, providing air traffic controllers instant access to two USB / DisplayPort-interfaced ATC computers for crucial operations. Port switching is flexible via pushbuttons, hotkeys, mouse, RS-232 commands, or an optional accessory the remote port selector.

With two lockable DC jacks for power redundancy, the CS1922ATC ensures uninterrupted operation and constant availability for mission-critical applications. It aims to greatly minimize or eliminate the risk of downtime.

Patented ATEN technology – Video DynaSync™, and EDID expert™ , combined with DisplayPort 1.2 and video resolutions up to 4K @ 60 Hz, it delivers optimized display resolution with exceptional detail and clarity in all conditions.

The CS1922ATC creates a safer environment and enhanced operational efficiency for Air Traffic Control Towers, Approach Control Rooms, and Area Control Centers, specifically tailored the air traffic control industry.

Poorten & interfaces
Aantal computers 2
Aansluiting toetsenbord USB
Aansluiting muis USB
Aansluiting video DisplayPort
Aantal DisplayPorts 3
Console-poorten 3.5mm hoofdtelefoon, 3.5mm mic, DisplayPort, USB A, VGA (D-Sub)
Aantal USB-poorten console 2
Aantal Console DisplayPorts-poorten 2
USB-hub Ja
Aantal USB 3.2-hubpoorten type A (3.1 Gen 1) 2
USB-connectortype Micro-USB, USB Type-A
Audio-aansluitingen Ja
Hoofdtelefoonuitgangen 4
Aantal microfooningangen 4
RJ-11 ports kwantiteit 1
Aansluiting voor netstroomadapter Ja
Prestatie
HD type 4K Ultra HD
Maximum resolutie 4096 x 2160 Pixels
Videobandbreedte 60 Hz
Upgraden van firmware mogelijk Ja
Design
Kleur van het product Zwart
Materiaal behuizing Metaal
LED-indicatoren Ja
drukknop Ja
Sneltoetsen Ja
Beeldscherm
Ingebouwd display Ja
Energie
Stroombron DC
Ingangsspanning 12 V
Stroomverbruik (typisch) 16,09 W
Eisen aan de omgeving
Bedrijfstemperatuur (T-T) 0 - 20 øC
Temperatuur bij opslag -20 - 60 øC
Relatieve vochtigheid in bedrijf (V-V) 0 - 80 procent
Gewicht en omvang
Breedte 161 mm
Diepte 335 mm
Hoogte 65,5 mm
Gewicht 1,88 kg
Logistieke gegevens
Land van herkomst Taiwan
