2-port USB - 4k Hdmi Dual Display Secure KVM Switch
ITCurry #: 90314324 | Article #: CS1142H4C-AT-G-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
ATEN PSD PP v4.0 Secure KVM Switch CS1142H4C is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSD PP v4.0 Secure KVM Switch CS1142H4C is compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) standard certified by the National Information Assurance Partnership (NIAP).
ATEN PSD PP v4.0 Secure KVM Switch CS1142H4C provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, speaker set, and Common Access Card (CAC) reader between connected computers of various security classifications. Compliance with PSD PP v4.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtration and management, strict audio filtration, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.
To enhance security, ATEN PSD PP v4.0 Secure KVM Switch CS1142H4C only offers manual switching methods including front panel pushbuttons and Remote Port Selector (RPS) 1. With multi – layered security, ATEN PSD PP v4.0 Secure KVM Switch CS1142H4C ensures high-level desktop security and data safekeeping for applications such as government and military agencies, healthcare providers, banking and finance institutions, and other organizations that often handle sensitive or confidential data on separate networks.
| Poorten & interfaces | |
| Aantal computers | 2 |
| Aansluiting toetsenbord | USB |
| Aansluiting muis | USB |
| Aansluiting video | HDMI |
| Aantal HDMI-poorten | 4 |
| Aantal poorten USB 2.0 Type-B | 4 |
| Console-poorten | 3.5mm hoofdtelefoon, HDMI, USB A |
| Aantal USB-poorten console | 2 |
| Aantal HDMI-poorten | 2 |
| USB-hub | Ja |
| Aantal USB 2.0-Type-A-hubpoorten | 1 |
| Audio-aansluitingen | Ja |
| Hoofdtelefoonuitgangen | 2 |
| RJ-11 ports kwantiteit | 1 |
| Prestatie | |
| HD type | 4K Ultra HD |
| Maximum resolutie | 3840 x 2160 Pixels |
| Videobandbreedte | 60 Hz |
| Design | |
| Kleur van het product | Zwart |
| Materiaal behuizing | Metaal |
| Bekabelde afstandsschakelaar | Ja |
| LED-indicatoren | Ja |
| drukknop | Ja |
| Beeldscherm | |
| Ingebouwd display | Nee |
| Energie | |
| Stroombron | AC |
| Ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Stroom | 1 A |
| Stroomverbruik (typisch) | 5,4 W |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 50 øC |
| Temperatuur bij opslag | -20 - 60 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 0 - 80 procent |
| Gewicht en omvang | |
| Breedte | 163,9 mm |
| Diepte | 335 mm |
| Hoogte | 65,5 mm |
| Gewicht | 2,11 kg |
| Verpakking | |
| Verpakkingsvolume | 16423,771 cmü |
| Gewicht verpakking | 2,95 kg |
| Inhoud van de verpakking | |
| Meegeleverde kabels | AC |
| Gebruikershandleiding | Ja |
| Logistieke gegevens | |
| Netto gewicht kartonnen doos | 6,93 kg |
| (Buitenste) hoofdverpakking breedte | 420 mm |
| (Buitenste) hoofdverpakking lengte | 555 mm |
| (Buitenste) hoofdverpakking hoogte | 258 mm |
| (Buitenste) hoofdverpakking brutogewicht | 9,77 kg |
| (Buitenste) hoofdverpakking inhoud | 60031,715 cmü |
| Land van herkomst | Taiwan |
| Warranty | |
| Base Warranty | Non Non |
