Rack-mount Transfer Switch - Rack ATS, 16A, 230V, (2)IEC 309 in, (1)IEC 309 Out
ITCurry #: 0280D293 | Article #: AP7722A
Verwante producten
Product Informatie
Quick Transfer Rate
Transfer rate is within the industry standard and within the time power supplies will typically drop loads. The transfer of one power source to another is seamless to the connected equipment avoiding disruption of equipment performance.
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Remote Management Capabilities
Full-featured network management interfaces that provide standards-based management via Web, SNMP, and Telnet. Allows users to access, configure, and manage units from remote locations to save valuable time. Associated with this feature is the ability to quickly and easily upgrade the firmware via network download to installed units for future product enhancements.
Dual Input Power Sources
Supplies redundant AC power to connected equipment. Two AC lines power the unit and if the primary AC power fails, the unit will automatically switch to the alternative power source.
| Design | |
| PDU types | Geschakeld |
| Montage | Horizontaal |
| Kleur van het product | Zwart |
| Poorten & interfaces | |
| Aantal AC uitgangen | 1 AC-uitgang(en) |
| Input-connectietype | IEC 309 16A 2P+E |
| Output-aansluitingen | (1) IEC 309 16A (2P+E) |
| Kenmerken | |
| Snoerlengte | 0,91 m |
| Energie | |
| Nominale input voltage | 208 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Stroom (max.) | 16 A |
| Netspanning, in bedrijf | 230 V |
| Laad-capaciteit | 3840 VA |
| Maximale ingang stroom per fase | 16 A |
| Maximum totaalstroomverbruik per fase | 16 A |
| Certificaten | |
| Certificaten van naleving | RoHS |
| Certificering | C-tick, CE, EN 55022 Class A, EN 55024, GOST, TUV, VCCI Class A, REACH |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -5 - 45 øC |
| Temperatuur bij opslag | -25 - 65 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 0 - 95 procent |
| Luchtvochtigheid bij opslag | 0 - 95 procent |
| Hoogte bij opslag | 0 - 15000 m |
| Gewicht en omvang | |
| Breedte | 432 mm |
| Diepte | 236 mm |
| Afmetingen (B x D x H) | 432 x 236 x 44 mm |
| Hoogte | 44 mm |
| Gewicht | 4,21 kg |
| Verpakking | |
| Afmetingen verpakking (BxDxH) | 600 x 349 x 114 mm |
| Gewicht verpakking | 5,95 kg |
| Breedte verpakking | 600 mm |
| Diepte verpakking | 349 mm |
| Hoogte verpakking | 114 mm |
| Warranty | |
| Base Warranty | Non Non |
