Ves1724 55c - Temperature Hardened Vdsl2 Box Dslam - 24 Port
ITCurry #: 62304818 | Article #: VES1724-55C-EU01V1F-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Compliant with ITU-T G.993.2, G994.1, G.997.1, G.998.4 G.inp, and G.993.5 vectoring
The VES1724-55C conforms to G.993.2, G994.1 G.997.1, G.998.4 G.inp, and G.993.5 vectoring to ensure the interoperability with standard-compliant VDSL CPE.
Ultra high-speed transmission with 17a profile support
The VES1724-55C supports 17a profile with 100 Mbps in downstream traffics. With two Gigabit combo ports to connect upper layer aggregation networks, the VES1724-55C can support low-concentration interconnection from the subscriber ports to the network interface ports.
Triple Play ready
The VES1724-55C supports IGMP snooping to prevent unnecessary forwarding of multicast traffic to all subscribers and thus optimizes bandwidth utilization for multicast applications such as broadcast video.The VES1724-55C also supports the multicast VLAN feature that distributes the source to all the VLANs requesting the video stream. With a built-in splitter over POTS, the VES1724-55C allows the operators to provide Triple Play services over the same copper wire.
Complete QoS for service differentiation
The VES1724-55C supports not only 802.1X port-based access control for subscriber authentication, but also defines a limited number of MAC addresses that can access the network from a particular port. With rate limiting on the subscriber ports allowing services to take advantage of 64 Kbps increments, service providers will be in a better position to offer tiered services.
| Management features | |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| MIB support | MIB II, RFC1493, 2674, 1757 MIB, private MIB |
| Ports & interfaces | |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p |
| Data transmission | |
| MAC address table | 1600 entries |
| Security | |
| MAC address filtering | Yes |
| Multicast features | |
| Multicast support | Yes |
| Design | |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Wall mountable | Yes |
| Safety | EN60950-1, CSA60950-1 |
| Certification | FCC Part 15 Class A, EN55022 Class A, ETSI300-386, RoHS, K.20, ETSI300-019 |
| Power | |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 63 W |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 65 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 250 mm |
| Height | 44.4 mm |
| Weight | 4.7 kg |
| Packaging data | |
| User guide | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Package type | Box |
| Package width | 550 mm |
| Package depth | 395 mm |
| Package height | 175 mm |
| Package weight | 5.3 kg |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
