SSD - Ultrastar DC SN630 - 3200GB - Pci-e Gen 3.1 x4 - U.2 2.5in - 2 DW/D
ITCurry #: 60505504 | Article #: 0TS1639-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Accelerate Access to Critical Data for Data-Intensive Workloads and Applications
Ultrastar NVMe series SSDs perform at the speed of today’s business needs. Enabling faster intelligence and access to critical data, these SSDs meet the growing digital demands of your business applications. Our top-end Ultrastar DC SN200 drive delivers extreme performance and ultra-low latency to the top tier of enterprise storage. It takes hyper-converged infrastructure (HCI) system throughput to new levels and helps scale on-line transaction processing (OLTP). Our Essential NVMe drives, Ultrastar DC SN620 and DC SN630, offer low latency and higher bandwidth for a seamless transition away from SATA SSDs in mixed-use and read-intensive applications. This combination of high throughput and predictable low latency delivers high performance for deeper insights and faster results for today’s data intensive applications.
Maximum Throughput
Up to 1.2M read IOPS to help power through demanding workloads
Low Latency
Predictable throughput for high-transaction workloads
Design Flexibility
Choice of form factors to support range of data centers requirements
| Features | |
| NVMe version | 1.3 |
| SSD form factor | 2.5" |
| SSD capacity | 3.2 TB |
| Interface | U.2 |
| Memory type | 3D TLC |
| NVMe | Yes |
| Component for | NAS |
| Hardware encryption | No |
| Read speed | 2500 MB/s |
| Write speed | 1200 MB/s |
| Random read (4KB) | 332510 IOPS |
| Random write (4KB) | 88140 IOPS |
| Read latency | 239 æs |
| PCI Express interface data lanes | x4 |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^10 bits read |
| Mean time between failures (MTBF) | 2000000 h |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| SSD usage tag | Data center |
| Power | |
| Operating voltage | 12 V |
| Power consumption (read) | 8.75 W |
| Power consumption (idle) | 5.9 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 78 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Weight & dimensions | |
| Width | 69.8 mm |
| Depth | 100.5 mm |
| Height | 7 mm |
| Weight | 95 g |
| Logistics data | |
| Harmonized System (HS) code | 84717070 |
| Other features | |
| SSD endurance rating | 2 DWPD |
| Warranty | |
| Base Warranty | Non Non |
