Product Information
Liebert PSP 500VA is a full featured UPS that delivers cost-effective power protection in a compact package. The UPS provides battery-backed outlets and a surge protection only outlet. The UPS battery offers four minutes of backup power at full load - ample time to shut down protected equipment if an outage occurs.
Warranty | |
Base Warranty | Non Non |
Features | |
UPS topology | Standby (Offline) |
Output power capacity | 0.5 kVA |
Output power | 300 W |
Waveform | Stepwise |
Input operation voltage (min) | 160 V |
Input operation voltage (max) | 287 V |
Input frequency | 50/60 Hz |
Output frequency | 50/60 Hz |
Response time | 6 ms |
Number of input phases | 1 |
Number of output phases | 1 |
Power factor | 0.6 |
Ports & interfaces | |
AC outlet types | IEC 320, C13 coupler |
Power plug | C14 coupler |
AC outlets quantity | 4 AC outlet(s) |
USB port | Yes |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
Battery | |
Battery technology | Sealed Lead Acid (VRLA) |
Battery capacity | 7 VAh |
Battery voltage | 12 V |
Number of batteries supported | 1 |
Typical backup time at half load | 11 min |
Battery recharge time | 8 h |
Design | |
Form factor | Tower |
Cooling type | Passive |
Product colour | Black |
International Protection (IP) code | IP20 |
Safety | IEC/EN/AS 62040-1-1 |
Certification | CE |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 øC |
Storage temperature (T-T) | -15 - 40 øC |
Operating relative humidity (H-H) | 0 - 90% |
Storage relative humidity (H-H) | 0 - 90% |
Operating altitude | 0 - 3000 m |
Technical details | |
Compliance certificates | RoHS |
Weight & dimensions | |
Width | 87 mm |
Depth | 215 mm |
Height | 251 mm |
Weight | 4.8 kg |
Package width | 151 mm |
Package depth | 419 mm |
Package height | 251 mm |
Package weight | 10.6 kg |
Logistics data | |
Harmonized System (HS) code | 85078000 |
Other features | |
Battery type | VDC x Ah |
Interface | IEC-320-C14 |
Dimensions (WxDxH) | 87 x 215 x 251 mm |
