DIN Rail - Panel Mount UPS with Standard Battery 500VA 325 Watts 230V
ITCurry #: 0280D551 | Article #: SUA500PDRI-S
slide 1 of 1
Related products
slide 7 to 11 of 14
Product Information
| Warranty | |
| Base Warranty | Non Non |
| Features | |
| Output power capacity | 0.5 kVA |
| Output power | 325 W |
| Input operation voltage (min) | 151 V |
| Input operation voltage (max) | 302 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 540 J |
| Efficiency | 94% |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Noise level | 55 dB |
| Surge protection | Yes |
| Ports & interfaces | |
| RS-232 ports | 1 |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Number of batteries supported | 1 |
| Design | |
| Product colour | Black |
| Certification | CE, VDE |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -15 - 45 øC |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Technical details | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 362 mm |
| Depth | 171 mm |
| Height | 148 mm |
| Weight | 12.9 kg |
| Package width | 297 mm |
| Package depth | 481 mm |
| Package height | 297 mm |
| Package weight | 13.3 kg |
| Packaging data | |
| Manual | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
DIN Rail - Panel Mount UPS with Standard Battery 500VA 325 Watts 230V
549.02
