EDGE UPS 1.5kVA 230V Tower
ITCurry #: N6415220 | Article #: EDGE-1500IMT-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The Vertiv Edge uninterruptible power supply (UPS) is designed to protect server and networking equipment in distributed and Edge IT applications. This 1500VA UPS mini-tower offers powerful and reliable protection from downtime and damage caused by power spikes, swells and brownouts. Automatic Voltage Regulation (AVR) extends battery life and safeguards critical equipment. With sine wave output, this line interactive UPS ensures availability of network closets and Edge data centers. It operates at up to 98% efficiency in normal operation mode, providing energy savings. Add optional Vertiv Intellislot SNMP/Webcards for remote power management and OS's shutdown with free Vertiv Power Assist software. The Edge family has a wide range of power ratings, from 500VA up to 3000VA and is available in multiple form factors: mini-tower, 1U rack and rack/tower. It is easy to install, configure and operate and comes with intuitive, color LCD screen.
| Warranty | |
| Base Warranty | Non Non |
| Features | |
| UPS topology | Line-Interactive |
| Output power capacity | 1.5 kVA |
| Output power | 1350 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 166 V |
| Input operation voltage (max) | 278 V |
| Input frequency | 45/65 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 624 J |
| Country of origin | China |
| Ports & interfaces | |
| AC outlet types | C13 coupler |
| Power plug | C14 coupler |
| AC outlets quantity | 5 AC outlet(s) |
| USB port | Yes |
| Battery | |
| Battery recharge time | 3 h |
| Design | |
| Form factor | Tower |
| Product colour | Black |
| Display type | LCD |
| Safety | Safety IEC/EN62040-1 |
| Certification | CE, CB Report, EAC, RCM, UKCA |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -25 - 55 øC |
| Operating relative humidity (H-H) | 20 - 90% |
| Operating altitude | 0 - 3000 m |
| Technical details | |
| Compliance certificates | CE, RoHS |
| Weight & dimensions | |
| Width | 145 mm |
| Depth | 480 mm |
| Height | 220 mm |
| Weight | 20 kg |
| Package width | 230 mm |
| Package depth | 570 mm |
| Package height | 325 mm |
| Package weight | 23 kg |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
| Nominal output voltage | 200-240 V |
| Nominal input voltage | 230 V |
