Uisp Console
ITCurry #: N3302883 | Article #: UISP-CONSOLE
slide 2 of 7
Price:
269.05
Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Related products
slide 7 to 11 of 14
Product Information
The UISP® Console is designed to support small to moderate UISP deployments with its built-in switch equipped with (8) GbE RJ45 LAN ports. The UISP Console also serves as a high-performance gateway with (1) 10G SFP+ LAN port and (2) WAN ports (10G SFP+ and GbE RJ45) that provide an ample connectivity range capable of supporting the most data-intensive deployments.
| Design | |
| Product colour | White |
| Rack capacity | 1U |
| Enclosure material | Metal |
| LED indicators | Yes |
| Certification | CE, FCC, IC |
| Performance | |
| Control display unit | No |
| Built-in processor | Yes |
| Processor family | ARM Cortex |
| Processor model | Cortex-A57 |
| Processor frequency | 1700 MHz |
| Number of processors installed | 1 |
| Internal memory | 4 MB |
| Internal memory type | DDR4 |
| SSD capacity | 128 GB |
| Flash memory | 16000 MB |
| Network | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 8 |
| WAN connection | Ethernet (RJ-45) |
| Power | |
| Power consumption (max) | 30 W |
| Input voltage | 24 - 28 V |
| Weight & dimensions | |
| Width | 210.4 mm |
| Depth | 140.2 mm |
| Height | 43.7 mm |
| Weight | 1.45 kg |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 50 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Warranty | |
| Base Warranty | Non Non |
