Docking Station - Hyperdrive Gen2 14-port Thunderbolt 3
ITCurry #: 55907684 | Article #: HDG2TB314-EU-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The HyperDrive GEN2 14-Port Thunderbolt™ 3 Docking Station is a powerful, enterprise-level Dock featuring 14 ports and boasts 2X faster refresh rate, 2X faster data transfer speeds and 2X faster power delivery charging. One TB3 downstream port provides 40Gbps data transfer and 15W of power for any TB3 peripherals while the one TB3 upstream port supplies 85W power delivery to the host computer. It allows dual 4K 60Hz display support for MST enabled devices, and offers Gigabit Ethernet, Digital Coaxial and Optical Toslink audio. Additionally, you can daisy chain six TB3 Docks or devices to HyperDrive. One DC 180W power adapter included.
Thunderbolt 3 Speeds
The Thunderbolt 3 upstream port provides 40Gbps data transfer and 85W Power Delivery to the host computer while the downstream port provides 40Gbps data transfer, 15W of power for any peripherals and DP 1.4 video.
Daisy Chain Six TB3 Devices
Maximize your workflow by daisy chaining up to 6 x Thunderbolt 3 docks or devices to HyperDrive.
Dual 4K 60Hz Display Support
HyperDrive supports dual 4K 60Hz display support for MST enabled devices through TB3 and DP 1.4 connection.
Fast & Reliable Gigabit Ethernet
Get the most reliable and fastest internet connection for work, play, and video conferencing.
High-Speed USB
Blazing-fast 2nd generation USB-A 3.2 10Gbps and USB-C 3.2 10Gbps with 2X faster transfer speed than our 1st generation hubs.
Pro-Grade Digital Audio
Capture and listen to the best sound quality possible with digital coaxial audio, optical Toslink audio, and a 3.5mm Audio Combo Jack.
| Ports & interfaces | |
| Host interface | Thunderbolt 3 |
| Hub interfaces | 3.5mm, DisplayPort, RJ-45, Thunderbolt 3, USB 3.2 Gen 2 (3.1 Gen 2) Type-A, USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 Type-C ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Thunderbolt ports quantity | 2 |
| Ports quantity | 13 |
| Ethernet LAN (RJ-45) ports | 1 |
| Features | |
| Data transfer rate | 40000 Mbit/s |
| Maximum refresh rate | 60 Hz |
| Supported graphics resolutions | 3840 x 2160 |
| Supported video modes | 2160p |
| Product colour | Grey |
| Network | |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power | |
| Power supply type | DC |
| Weight & dimensions | |
| Width | 130.2 mm |
| Depth | 88.9 mm |
| Height | 44.5 mm |
| Weight | 680 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
