Tv Wall Mount For 32in To 70in Flat-screen Tv - With Tilt (flatpnlwall)
ITCurry #: 75647267 | Article #: FLATPNLWALL-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Display Wall Mount | Steel | For 32" to 75" TVs
Maximize space while creating an impressive display with this flat-screen TV wall mount for large TVs or monitors. The heavy-duty wall mount securely supports a VESA Mount compliant TV from 32" to 75"; with easy-to-use tilt adjustment for comfortable viewing.
Ideal for the Boardroom, or Digital Signage
Mount your flat-screen TV in a location that's convenient for visitors, clients and employees, while saving valuable space. The wall mount is ideal for boardrooms, lobbies or other venues providing an impressive and secure way to display a large flat-panel TV or create digital signage. The robust wall mount supports a large 32" to 75" flat-screen TV weighing up to 165 lb. (75 kg).
Tilt Your Display to the Ideal Viewing Angle
The TV wall mount lets you angle your TV display toward your audience. With the tilt feature, you can mount your TV lower or higher than eye level and still view it comfortably. The tilt-adjusting knobs make it easy to adjust your TV to the ideal viewing angle.
Easy and Secure Setup
The hook-and-mount design of the TV wall mount makes setup fast and easy. You simply attach the vertical brackets, with built-in hooks, to the back of your TV. Once the brackets are attached, you then hang your TV securely onto the wall mount. Cable management helps to keep cables out of view.
The StarTech.com Advantage
Mounting | |
Minimum screen size | 81.3 cm (32") |
Maximum weight capacity | 75 kg |
Maximum screen size | 190.5 cm (75") |
Minimum VESA mount | 75 x 75 mm |
Maximum VESA mount | 600 x 400 mm |
Panel mounting interface | 75 x 75,100 x 100,100 x 200,200 x 100,200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,400 x 400,400 x 300,600 x 200,600 x 300,600 x 400 |
Number of displays supported | 1 |
Mounting type | Wall |
Ergonomics | |
Tilt angle range | -15 - 15ø |
Cable management | Yes |
Distance to the wall (min) | 8.3 cm |
Design | |
Product colour | Black |
Warranty | |
Base Warranty | Non Non |
Technical details | |
Compliance certificates | RoHS |
Packaging content | |
Adapter bracket included | Yes |
Number of adapter brackets included | 2 |
Anchors included | Yes |
Number of anchors included | 6 |
Wrench included | Yes |
Washers included | Yes |
Wrench type | Hexagonal wrench |
Number of washers included | 10 |
Spacer included | Yes |
Number of spacers included | 16 |
Screws included | Yes |
Number of screws | 26 |
Manual | Yes |
Mounting kit | Yes |
Weight & dimensions | |
Width | 83 mm |
Depth | 810 mm |
Depth (max) | 81 cm |
Height | 500 mm |
Weight | 3.8 kg |
Packaging data | |
Package width | 238 mm |
Package depth | 835 mm |
Package height | 89 mm |
Package weight | 4.9 kg |
Logistics data | |
Master (outer) case width | 280 mm |
Master (outer) case length | 853 mm |
Master (outer) case height | 254 mm |
Products per master (outer) case | 3 pc(s) |
Harmonized System (HS) code | 85299097 |
