NAS - TS-H1677AXU-RP-R7-32G - 16Bay - Ryzen 7 7000 -32 DDR5

ITCurry #: N222A491 | Article #: TS-H1677AXU-RP-R7-32G
Flash Sale
Price:
4801.42 Inc VAT Ex VAT
Shipping:
Out of Stock. Contact Us!
Email us for assistance
Key Specifications
  • Screen
    Memory
    Weight
    Processor
    Hard Disk
    SSD
    Screen
    Resolution
    Connectivity
    Memory
    Case
    OS
    Screen
    Type
    Speed Black
    Speed Colour
    Model
    Processor Speed
    Form Factor
    Internal / External
    Port Count
    Uplink / media
    Mounting
  • View All Specs

Bundles

Inc VAT Ex VAT
Out of Stock. Contact Us!
Inc VAT Ex VAT
Out of Stock. Contact Us!

Inc VAT Ex VAT
Out of Stock. Contact Us!

Inc VAT Ex VAT
Out of Stock. Contact Us!

Related products

Product Information

Storage
Storage drive capacity 0 GB
Supported storage drive interfaces M.2, Serial ATA III, Serial ATA II
Storage drive sizes supported 2.5,3.5"
Number of system drives supported 2
Number of M.2 (M & B) slots 2
RAID support Yes
RAID levels 0, 1, 5, 6, 10, 50, 60, JBOD
Online RAID migration Yes
Online RAID expansion Yes
RAID rebuild Yes
Hot-swap drive bays Yes
Supported file systems FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage drives installed No
Total installed storage capacity 0 TB
Number of storage drives supported 16
Installed storage drive type No
Supported storage drive types HDD & SSD
Bad block scan Yes
Disk roaming Yes
Processor
Processor manufacturer AMD
Processor generation AMD Ryzen PRO 7000 Series
Processor family AMD RyzenT 7
Processor model 7745
Processor boost frequency 5.3 GHz
Processor cores 8
Processor threads 16
Number of processors supported 1
On-board graphics card model AMD Radeon Graphics
Memory
Internal memory 32 GB
Internal memory type DDR5
Maximum RAM supported 128 GB
Memory slots 4
Memory form factor UDIMM
Flash memory 5000 MB
Network
Ethernet LAN Yes
Ethernet LAN data rates 100,1000,2500,10000 Mbit/s
Ethernet LAN data rate supported (max) 10000 Mbit/s
DHCP server Yes
iSCSI support Yes
Supported network protocols IPv4, IPv6
Dynamic DNS (DDNS) Yes
Ports & interfaces
USB port Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2
Ethernet LAN (RJ-45) ports 4
Design
Chassis type Rack (3U)
Cooling type Active
Product colour Black, Grey
Number of fans 3 fan(s)
Fan diameter 6 cm
LED indicators HDD, LAN, SSD, Status, USB
Performance
Type Storage server
Device class Small & Medium Business
Backup function Yes
Backup features Cloud, USB drive, iSCSI LUN
Buzzer Yes
Multilingual support Yes
Number of users 4096 user(s)
Web-based management Yes
Remote administration PPTP, L2TP/IPSec, OpenVPN, WireGuard, QBelt
Reset button Yes
On/off switch Yes
Built-in FTP server Yes
System log Yes
Password authentication Yes
Disk scan Yes
S.M.A.R.T. support Yes
Share folder Y
Software
Operating system installed QNAP QTS
Operating system version 5.2.6
Power
Power supply location Built-in
Power supply unit (PSU) capacity 550 W
Number of power supply units 2
Redundant power supply (RPS) support Yes
AC input voltage 100 - 240 V
Weight & dimensions
Width 482.2 mm
Depth 550.8 mm
Height 131.3 mm
Weight 15.6 kg
Package width 567 mm
Package depth 724 mm
Package height 313 mm
Package weight 19.6 kg
Packaging content
Cables included AC, LAN (RJ-45)
Number of screws 128
Drive tray key included Yes
Package type Box
Operational conditions
Operating temperature (T-T) 0 - 40 øC
Operating relative humidity (H-H) 5 - 95%
Storage temperature (T-T) -20 - 70 øC
Other features
Warranty period 5 year(s)
Warranty
Base Warranty Non Non
