IoT Mini Server 2 Bay 1.7GHz Qc 2GB 3c Gbe 2x USB3.0
ITCurry #: N2227751 | Article #: QBOAT SUNNY-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The QBoat Sunny is a dedicated single-board Internet of Things (IoT) mini server for IoT developers and provides high expandability for connecting many IoT devices. Featuring Container Station and QIoT Suite Lite, the QBoat Sunny allows you to seamlessly manage and monitor your IoT applications, devices, and data for a streamlined and highly efficient IoT development experience. In the era of IoT, the QBoat Sunny is the ark to ferry your IoT devices and applications, and act as a private and/or public server/gateway.
The first single-board IoT mini server/gateway for developers
The QBoat Sunny is the first single-board IoT mini server by QNAP. Measuring only 12cm x 12cm (without heatsink), the development board-like design can be effortlessly installed for almost any type of IoT application, while providing several interfaces for connecting to development boards and devices. Rule engine criteria and subsequent actions can be processed locally for you to create a small-scale/private IoT application with minimal costs. The QBoat Sunny can also reduce bandwidth and cloud processing costs of large scale/public IoT solutions by using it as a fog computing server/gateway to filter and relay data to public clouds.
Compact and powerful
The QBoat Sunny is powered by a high-performance AL-314 quad-core processor with 2 GB RAM and comes with multiple expansion slots and interfaces to satisfy all your IoT development needs. The QTS Lite operating system also provides all the functionality needed for your IoT environments.
QTS Lite operating system carries all IoT applications
QTS Lite is a streamlined and thin version of QNAP's award-winning QTS operating system. QTS Lite provides Container Station to run containerized applications; myQNAPcloud for remote connectivity; Hybrid Backup Sync for backup and synchronization needs; and Network & Virtual Switch for managing network connections and linking containers, networks and the QBoat Sunny. QTS Lite also features App Center for adding more features and functionality.
Migrate existing environments to QBoat Sunny using Container Station
If you have already set up an IoT environment, it can be easily migrated to the QBoat Sunny with container virtualization. Container Station is compatible with Docker and LXC containers and allows you to seamlessly transfer your existing applications to the QBoat Sunny and to further enhance and expand your IoT environment.
Simplified development with QIoT Suite Lite
QIoT Suite Lite integrates multiple easy-to-use and useful applications for you to quickly build an ideal IoT environment. Versatile protocols (such as MQTT(S), HTTP(S) and CoAP) and dashboards are available for you to integrate development boards and sensors to build a complete IoT ecosystem. If you're new to the immerse IoT domain, the QIoT Suite Lite will be your excellent choice.
| Processor | |
| Processor frequency | 1.7 MHz |
| Processor manufacturer | Annapurna Labs |
| Processor model | AL-314 |
| Processor cores | 4 |
| Memory | |
| Maximum internal memory | 2 GB |
| Internal memory type | DDR3L |
| Memory bandwidth (max) | 6 GB/s |
| Flash memory | 512 MB |
| Flash memory type | NAND |
| SSD form factor | M.2 |
| Ports & interfaces | |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 2 |
| Audio port type | 3.5mm |
| Ethernet LAN (RJ-45) ports | 3 |
| Number of SATA III connectors | 1 |
| Number of M.2 (M) slots | 2 |
| Features | |
| Form factor | System on Module |
| On/off button | Yes |
| Reset button | Yes |
| Weight & dimensions | |
| Board dimensions | 126 x 33.5 mm |
| Height | 33.5 mm |
| Weight | 490 g |
| Width | 144 mm |
| Depth | 126 mm |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Other features | |
| Power consumption (typical) | 13.31 W |
| Power consumption (idle) | 9.49 W |
| LED indicators | SSD, Status, WAN |
| Packaging data | |
| Package weight | 1.05 kg |
| Warranty | |
| Base Warranty | Non Non |
