Matrox Maevex 7112A Single-Channel 4K Encoder
A single-channel H.264 encoder, Matrox Maevex 7112A delivers 4K60 input capture and encode with zero-latency pass-through. Maevex 7112A supports multiple streaming protocols, multiple chroma sub-sampling, and adjustable encoding parameters. All of this is packaged in a fanless, low power, rack-ready appliance. Maevex 7100 Series includes the PowerStream Plus application and Command Center, a convenient new web user interface. TAA-compliant SKUs are available.
H.264 interoperability. Low bandwidth.
• Transport secure, low latency, 4K60 video over any network at extremely low bitrates—ideal for live, real-time applications.
• Tailor encoding settings to meet diverse application requirements, whether it’s achieving ultra-low latency, minimizing bitrates, or encoding desktop content.
Enterprise-grade security
• Integration with Microsoft Active Directory for access control
• HTTPS communication for secure device control
• Secure and verified firmware and vulnerability updates
• 802.1x support for network authentication
• SRT support with AES encryption
Single stream and record. Ultimate convenience.
Deliver source content to on-premises end points over LAN, WAN (VPN), and internet. Feed cloud-based servers, and record to any accessible network location, including a NAS and NVR, for after action review—all in a compact form factor. You can also leverage RTMP for seamless cloud integration and reliable video streaming. Support for the Secure Reliable Transport (SRT) protocol ensures that reliable, high-quality streaming is also possible on noisy or unpredictable networks.
Rack mountable. Ultra quiet operation.
The Maevex 7112 encoder is a stand-alone appliance housed in a 1U ? rack width. Place the appliance on the desktop, workstation, or rack, and it’s ready to use.
And its fanless operation means that Maevex is made for control rooms, operation centers, and other critical environments that require a noise level of 25 dB and less.
| Video | |
| Maximum video resolution | 3840 x 2160 pixels |
| Maximum frame rate | 60 fps |
| Video compression formats | AVC, H.264 |
| Performance | |
| HDD interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
| Audio compression formats | AAC |
| Web-based management | Yes |
| Firmware upgradeable | Yes |
| Compatible operating systems | Matrox PowerStream Plus Sofware (free download): Microsoft© Server© 2022, Windows© Server© 2019, Windows© 11, Windows© 10 |
| Network | |
| Copper ethernet cabling technology | 1000BASE-T |
| Networking standards | IEEE 802.1x |
| Ports & interfaces | |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 1 |
| HDMI version | 2.0 |
| Audio connector type | 3.5 mm (1/8") |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Power | |
| Power consumption (typical) | 12 W |
| Input voltage | 12 V |
| Weight & dimensions | |
| Width | 217 mm |
| Depth | 191 mm |
| Height | 43 mm |
| Weight | 350 g |
| Packaging content | |
| Power adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Warranty | |
| Base Warranty | Non Non |
