Product Information
The dual-processor ThinkSystem SR630 V3 server is a 1U server maximized for performance. With the 4th Gen Intel® Xeon®Scalable processors it provides up to 59% better performance over the previous generation. When you factor in 32 DIMMs of DDR5 memory, PCIe Gen5 technology, up to EDSFF E1.S drives thru direct NVMe, it offers the speed and density desired by cloud service providers and enterprises.
Model Specs | |
Model | ThinkSystem SR630 V3 |
Form/Chassis type | 1U rack |
CPU | |
Processor | Xeon Sixteen-Core |
Processor Type | Intel® Xeon® |
Processor Speed | Xeon® Sixteen-Core Gold 5416S 2.00 GHz |
Processor Supported | 2 |
Memory | |
Memory Type | TruDDR5 3DS/RDIMMs |
Memory Std. | 64 GB |
Memory Max. | 8 TB |
Drives / Storage | |
Hard Disk Capacity | 0 GB |
Graphics | |
Video Adapter | Up to 3x 75W GPUs for graphics-intensive workloads |
Interfaces | |
Ports - USB | Front: 1x USB 3.1 G1, 1x USB 2.0 for BMC Rear: 3x USB 3.0 G1 |
Ports - RJ-45 | Rear:1x 1GbE RJ45 (management), 2nd 1GbE management port (optional in OCP slot location), and 1x Serial port (optional) |
Ports - Monitor | 1x VGA (optional) Rear: 1x VGA |
Ports - Other | 1x external diagnostics handset port (optional) |
Power Supply | |
Voltage / Watt | Dual Redundant AC & DC; Platinum & Titanium; 750W, 1100W, 1800W, and 1100W -48V DC Platinum |
General | |
OS | Microsoft, SUSE, Red Hat, VMware |
Certificates | |
Green Compliant | Yes |
Energy Star Certified | Yes |
Warranty | |
Base Warranty | Non Non |
