The Lenovo ThinkSystem NE1032 RackSwitch is a 1U rack-mount 10 Gb Ethernet switch that delivers lossless, low-latency performance with feature-rich design that supports virtualization, Converged Enhanced Ethernet (CEE), high availability, and enterprise class Layer 2 and Layer 3 functionality. The switch delivers line-rate, high-bandwidth switching, filtering, and traffic queuing without delaying data.
This product guide provides essential pre-sales information to understand the NE1032 RackSwitch, its key features and specifications, components and options, and configuration guidelines.
This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the NE1032 RackSwitch and consider its use in IT solutions.
| Warranty | |
| Base Warranty | Non Non |
| Management features | |
| Switch type | Managed |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Cloud-managed | Y |
| Traffic classification | Y |
| Traffic shaping | Y |
| System event log | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| QSFP+ module slots quantity | 32 |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Y |
| Port mirroring | Y |
| Full duplex | Y |
| IP routing | Y |
| Policy-based routing | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Spanning tree protocol | Y |
| VLAN support | Y |
| Number of VLANs | 4095 |
| Data transmission | |
| Static route | Y |
| Number of static routes | 256 |
| Jumbo frames support | Y |
| Jumbo frames | 9216 |
| Security | |
| Access Control List (ACL) | Y |
| Access Control List (ACL) egress | 512 |
| Access Control List (ACL) ingress | 3072 |
| IGMP snooping | Y |
| SSH/SSL support | Y |
| Multicast features | |
| Multicast support | Y |
| Design | |
| Rack mounting | Y |
| Form factor | 1U |
| Product colour | Black |
| Performance | |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power supply included | Y |
| Redundant power supply (RPS) support | Y |
| Number of power supply units | 2 |
| AC input voltage | 90 - 240 V |
| Weight & dimensions | |
| Width | 441 mm |
| Depth | 487 mm |
| Height | 44 mm |
| Weight | 10.7 kg |
