The Lenovo ThinkSystem NE1032 RackSwitch is part of the Lenovo Top of Rack (ToR) RackSwitch enterprise switch family, tested and validated with Lenovo reference architectures to provide the best integration possible for Lenovo servers, storage, and networking in the data center. RackSwitches interoperate seamlessly with other vendors' hardware and management. In addition, Lenovo XClarity provides easy single-pane-of-glass management for the Lenovo data center.
Data center optimized networking
The NE1032 is optimized for enterprise data centers with features, such as:
- Software Defined Data Center interfaces ensure smooth interoperability with popular enterprise management applications.
- Nutanix Prism with Lenovo ThinkAgile Network Orchestrator automates vlan changes to improve uptime and network security.
- VMware vRealize Log Insight collects logs and events to determine root cause and produce reports across multiple devices and vendors.
- VMware vRealize Network Orchestrator helps deploy workflows to automate complex IT processes.
- As a Microsoft Azure Stack solution partner, BGP, DCP, and switch-independent teaming deliver seamless interoperability.
- Open Architecture: NE1032 supports automation and control while integrating with industry-standard applications and APIs, such as REST, OpenStack, OpenContrail, and Ansible.
- OpenStack controls diverse pools of processing, storage, and networking resources throughout the data center.
- Ansible, Puppet, and Chef automation integration frees up operations teams for more strategic work.
- Resiliency: NE1032 offers outstanding fault tolerance with one of the quickest high-availability failovers in the industry.
Low TCO
NE1032 is an extremely cost-effective switch for low-end 10GbE hybrid cloud data center applications. It offers the following reduced costs:
- All software, management plugins, and XClarity Administrator are included in the purchase price.
- Switches come with a 3-year warranty and include free software updates and upgrades.
- Lower power consumption reduces operating expenses.
| Management features | |
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
| SFP+ module slots quantity | 32 |
| Console port | RJ-45/Mini-USB |
| USB 2.0 ports quantity | 1 |
| Power connector | AC-in jack |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| Link aggregation | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Number of VLANs | 4095 |
| Data transmission | |
| Switching capacity | 10 Gbit/s |
| Throughput | 640000 Mpps |
| MAC address table | 208000 entries |
| Latency (10 Gbps) | 0.76 æs |
| Static route | Yes |
| Number of static routes | 256 |
| Jumbo frames support | Yes |
| Jumbo frames | 9216 |
| Packet buffer memory | 12 MB |
| Security | |
| Access Control List (ACL) | Yes |
| Access Control List (ACL) egress | 512 |
| Access Control List (ACL) ingress | 3072 |
| Security algorithms | 802.1x RADIUS, SNMP, SNMPv3, SSH |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Management protocols | IPv4, IPv6 |
| Routing protocols | IP, VRRP |
| Design | |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| Reset button | Yes |
| Ventilation system | Front-to-back airflow |
| Number of fans | 3 fan(s) |
| Performance | |
| Mean time between failures (MTBF) | 196927 h |
| Power | |
| Power supply included | Yes |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| AC input voltage | 100 - 240 V |
| Weight & dimensions | |
| Width | 441 mm |
| Depth | 487 mm |
| Height | 44 mm |
| Weight | 10.7 kg |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Other features | |
| Power supply | 770 W |
| Warranty | |
| Base Warranty | Non Non |
