ThinkPad Universal Thunderbolt 4 Smart Dock - Thunderbolt / HDMI / 2x DP / 4x USB-A / 1x USB-C / 3.5mm / Gbe - 100W USB Power Delivery - EU
ITCurry #: M852QZ47 | Article #: 40B10135EU-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
A SMARTER WAY TO WORK.
The robust way to maximize productivity and the workspace, the Lenovo™ ThinkPad® Universal Thunderbolt™ 4 Smart Dock (40B10 is the leader in our new series of docks offering a smarter way to work. Capable of driving 8k displays and 40Gbps data speeds, the dock ushers in the next generation of Intel® Thunderbolt™ 4 connectivity for commercial users and a new cloud-based management paradigm for IT managers. And it’s all powered by Microsoft Azure Sphere.
Ports & interfaces | |
Connectivity technology | Wired |
Host interface | Thunderbolt 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
DisplayPorts quantity | 2 |
DisplayPort version | 1.4 |
Thunderbolt 4 ports quantity | 1 |
Combo headphone/mic port | Yes |
Headphone connectivity | 3.5 mm |
DC-in jack | Yes |
Network | |
Ethernet LAN | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Performance | |
Data transfer rate | 40 Gbit/s |
Number of displays supported | 4 |
Maximum refresh rate | 60 Hz |
Product colour | Black |
Certification | cULus, FCC, ICES, NOM |
Power | |
Power source type | DC |
Input current | 6.75 A |
Power consumption (max) | 100 W |
Software | |
Windows operating systems supported | Yes |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 øC |
Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions | |
Width | 220 mm |
Depth | 80 mm |
Height | 30 mm |
Weight | 460 g |
Packaging data | |
Package width | 270 mm |
Package depth | 195 mm |
Package height | 85 mm |
Package weight | 1.23 kg |
Packaging content | |
Cables included | AC, Thunderbolt |
AC adapter included | Yes |
Logistics data | |
Harmonized System (HS) code | 84733020 |
Warranty | |
Base Warranty | Non Non |
