Barebone Mini Pc Compute Element NUC Nuc9vxqnb - Xeon E 2286m Bulk
ITCurry #: 2730C718 | Article #: BKNUC9VXQNB-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® vPro™ Platform Eligibility
The Intel vPro® platform is a set of hardware and technologies used to build business computing endpoints with premium performance, built-in security, modern manageability and platform stability.
TPM
Trusted Platform Module (TPM) is a component on the desktop board that is specifically designed to enhance platform security above-and-beyond the capabilities of today's software by providing a protected space for key operations and other security critical tasks. Using both hardware and software, the TPM protects encryption and signature keys at their most vulnerable stages - operations when the keys are being used unencrypted in plain-text form.
TPM Version - Discrete 2.0
TPM (Trusted Platform Module) is a component that provides hardware level security upon system boot-up via stored security keys, passwords, encryption and hash functions.
Intel® Rapid Storage Technology
Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® Platform Trust Technology (Intel® PTT)
Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.
| Processor | |
| Processor manufacturer | Intel |
| Processor frequency | 2.4 GHz |
| Processor family | Intel Xeon E |
| Processor model | E-2286M |
| Processor cores | 8 |
| Processor boost frequency | 5 GHz |
| Processor cache | 16 MB |
| Processor threads | 16 |
| PCI Express slots version | 3.0 |
| Processor lithography | 14 nm |
| Configurable TDP-down | 35 W |
| Memory types supported by processor | DDR4-SDRAM |
| Memory bandwidth supported by processor (max) | 42.6 GB/s |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 64 GB |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 2666 MHz |
| Memory bandwidth (max) | 42.6 GB/s |
| ECC | Yes |
| Memory channels | Dual-channel |
| Supported memory types | DDR4-SDRAM |
| Storage | |
| Number of storage drives supported | 2 |
| Card reader integrated | No |
| Graphics | |
| On-board graphics card | No |
| On-board graphics card model | Intel UHD Graphics P630 |
| Discrete graphics card | No |
| Number of displays supported | 3 |
| Number of displays supported (on-board graphics) | 3 |
| Graphics output | 2x Thunderbolt 3, HDMI 2.0a |
| Network | |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| Thunderbolt 3 ports quantity | 2 |
| HDMI version | 2.0a |
| Ethernet LAN (RJ-45) ports | 2 |
| S/PDIF out port | Yes |
| Number of SATA III connectors | 3 |
| USB version | 2.0/3.2 Gen 2 (3.1 Gen 2) |
| USB ports quantity | 10 |
| Performance | |
| Motherboard chipset | Intel© CM246 |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Status | Launched |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| ARK ID | 199874 |
| Software | |
| Compatible operating systems | Windows 11 (64-bit), Windows 10 (64-bit) |
| Processor special features | |
| Intel Flex Memory Access | Yes |
| Intel© AES New Instructions (Intel© AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Embedded options available | No |
| Intel Rapid Storage Technology | Yes |
| Intel TSX-NI | Yes |
| Intel 64 | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Clear Video Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 192993 |
| Intel© OptaneT Memory Ready | Yes |
| Intel© Platform Trust Technology (Intel© PTT) | Yes |
| Intel© vProT Platform Eligibility | Yes |
| Weight & dimensions | |
| Width | 203 mm |
| Depth | 131 mm |
| Height | 38 mm |
| Packaging content | |
| Processor included | Intel© Xeon© E-2286M Processor (16M Cache, 2.40 GHz) |
| Logistics data | |
| Harmonized System (HS) code | 84713000 |
| Warranty | |
| Base Warranty | Non Non |
