Barebone Mini Pc Panther Canyon Nuc11pahi3 No Cord
ITCurry #: 2730C832 | Article #: RNUC11PAHI30000-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® HD Audio Technology
Intel® High Definition Audio (Intel® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel® HD Audio has the technology needed to support the latest and greatest audio content.
Intel® Rapid Storage Technology
Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® Platform Trust Technology (Intel® PTT)
Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.
| Processor | |
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor family | Intel© CoreT i3 |
| Processor generation | 11th gen Intel© CoreT i3 |
| Processor model | i3-1115G4 |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor lithography | 10 nm |
| Processor boost frequency | 4.1 GHz |
| Processor cache | 6 MB |
| CPU configuration (max) | 1 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 3200 MHz |
| Memory bandwidth (max) | 51.2 GB/s |
| Memory voltage | 1.2 V |
| ECC | No |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,M.2 |
| Storage drive interface | M.2, Serial ATA III |
| Graphics | |
| On-board graphics card | Yes |
| Graphics card family | Intel |
| On-board graphics card model | Intel© UHD Graphics |
| Number of displays supported | 4 |
| Network | |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6 AX201 |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| LAN controller | Intel I225-V |
| Bluetooth | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| Internal USB 2.0 ports quantity | 1 |
| Internal USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0a |
| Mini DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Thunderbolt ports quantity | 2 |
| Number of SATA III connectors | 2 |
| Design | |
| Chassis type | UCFF |
| Product colour | Black |
| On/off switch | Yes |
| Product type | Mini PC barebone |
| ARK ID | 205033 |
| Performance | |
| Motherboard form factor | UCFF |
| Trusted Platform Module (TPM) | No |
| Audio output channels | 7.1 channels |
| Consumer infrared Rx sensor | Yes |
| Processor special features | |
| Intel© vProT Platform Eligibility | No |
| Intel© High Definition Audio (Intel© HD Audio) | Yes |
| Embedded options available | No |
| Intel Rapid Storage Technology | Yes |
| Intel© AES New Instructions (Intel© AES-NI) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Idle States | Yes |
| Intel Trusted Execution Technology | No |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel© Platform Trust Technology (Intel© PTT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Logistics data | |
| Harmonized System (HS) code | 84713000 |
| Power | |
| Power supply type | External AC adapter |
| Power supply | 40 W |
| AC adapter output voltage | 19 V |
| Weight & dimensions | |
| Width | 117 mm |
| Depth | 112 mm |
| Height | 51 mm |
| Warranty | |
| Base Warranty | Non Non |
