Touch Monitor - ProLite TF1734MC-B7X - 17in - 1280x1024 (SXGA) - Black
ITCurry #: 89303004 | Article #: TF1734MC-B7X-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
17’’ 10pt touch Open Frame monitor with Touch Through-Glass function
The ProLite TF1734MC-B7X uses 10 pt Projective Capacitive touch technology built into an eye catching bezel with edge-to-edge glass, which guarantees high durability, scratch-resistance and perfect picture performance. The screen is IP65 rated which means it is dust and water resistant from the front. Together with the Touch-Through-Glass technology which delivers a seamless and accurate touch response, this makes the monitor an ideal solution for kiosk integrators, Instore Retail and behind-glass-retail.
TOUCH THROUGH-GLASS
This through glass touch screen works right through glass and can turn glass surfaces into an interactive touch screen display. Use it on storefront windows, real estate office, in-store for POS or restaurants.
SCRATCH RESISTANCE
Scratch resistance is essential for touch solutions used in public places and schools. This is achieved thanks to a glass overlay covering the screen. It guarantees high durability of the touch function and even more importantly the touch function remains unaffected even if the glass is scratched.
IP
The IP code classifies and rates the degree of protection against water intrusion. IP65 means that the monitor is protected to water splashes against the enclosure from any direction.
OPEN FRAME BRACKETS
This open frame monitor can be equipped with optional external mounting brackets. It guarantees easy installation and makes it an ideal solution for kiosk integrators and In-store Retail.
| Display | |
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1280 x 1024 pixels |
| HD type | SXGA |
| Display brightness | 350 cd/mý |
| Touchscreen | Yes |
| Pixel pitch | 0.264 x 0.264 mm |
| Contrast ratio (typical) | 1000:1 |
| Response time | 5 ms |
| Viewing angle, horizontal | 170ø |
| Viewing angle, vertical | 170ø |
| Native aspect ratio | 5:4 |
| Panel type | TN |
| Features | |
| Product colour | Black |
| Power | |
| AC adapter output voltage | 12 V |
| Packaging data | |
| Package width | 455 mm |
| Package depth | 145 mm |
| Package height | 387 mm |
| Package weight | 4.9 kg |
| Certificates | |
| Certification | CE, EAC, RoHS support, ErP, WEEE, cULus, REACH |
| Warranty | |
| Base Warranty | Non Non |
